Summary of Contents for Samsung DVD-R135
- Page 1 Instruction Manual DVD-R135 DVD-R136 www.samsung.com/uk English AK68-01085A-00...
-
Page 2: Warning
However, if there is no alternative to cutting off the plug, remove the fuse and then safely dispose of the plug. Do not connect the plug to a mains jack, as there is a risk of shock hazard from the bared flexible cord. -
Page 3: Precaution
● played, or the disc may be scratched or broken, the DVD Recorder's internal parts may be damaged. Do not put a flower vase filled with water or any small ● metal objects on the DVD Recorder. Be careful not to put your hand into the disc tray. -
Page 4: Disc Storage
Disc Storage Be careful not to harm the disc because the data on these discs is highly vulnerable to the environment. Do not keep under direct sunlight. ● Keep in a cool ventilated area. ● Store vertically. ● Keep in a clean protection jacket. - Page 5 DVD-RW (VR mode) ● - This is a format that is used for recording data on a DVD-RW disc. You can record multiple titles, edit, delete, partial delete, create a playlist, etc. - A disc that is recorded in this mode may not be played by existing DVD Recorder.
-
Page 6: Table Of Contents
Case 3: Connecting to an AV amplifier with a digital output jack ...21 Connecting HDMI/DVI to a TV ...21 Case 1 : Connecting to a TV with HDMI Jack ...21 Case 2 : Connecting to a TV with DVI Jack ...21 Connecting to AV3 IN, DV input jack...22 Case 1 : Connecting a VCR, Set-Top Box(STB), DVD player or Camcorder to the AV3 IN jacks ...22... - Page 7 Region code (DVD-Video only)...50 Disc types that can be played ...50 Discs that cannot be played ...50 Playing a Disc...51 Using the Disc Menu & Title Menu ...52 Using the Search Functions ...52 Slow Motion Play...53 Step Motion Play...53 About ANYKEY ...53 Using the Repeat Function...54...
-
Page 8: General Features
General Features The DVD Recorder allows you to record and play high quality digital video on DVD-RW/DVD-R discs. You can record and edit digital images on DVD-RW/DVD-R discs as if they were VCR tapes. High quality digital audio and video recording and playback Record up to 8-hours of images with a 4.7 GB... -
Page 9: Before Reading The User's Manual
Select the disc type This DVD Recorder can record on the following types of discs. If you want to repeatedly record on the same disc or you want to edit the disc after recording, select a rewritable DVD-RW type disc. - Page 10 LP (long recording mode), and EP (extended mode) according to the recording mode. When recording is set in the FR mode, the best quality picture is recorded with regards to the remaining time on the disc. Step 4...
-
Page 11: Unpacking
Instruction Manual Control (AAA Size) Quick Guide Preparing the Remote Control Install Batteries in the Remote Control Open the battery cover on the back of the remote ● control. Insert two AAA batteries. Make sure that the polarities ● (+ and -) are aligned correctly. - Page 12 10, 11, 12, 13, 14, 15, 16, 17, 18 BANG & OLUFSEN BLAUPUNKT BRANDT BRIONVEGA CONTINENTAL EDISON DAEWOO 19, 20, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34 EMERSON FERGUSON FINLUX 06, 49, 57 FORMENTI FUJITSU...
-
Page 13: Description
10. STOP Stops disc playback. 11. PLAY/PAUSE Plays a disc or pauses playback/recording. 12. SEARCH/SKIP Go to the next title/chapter/track or go back to the previous title/chapter/track. 7. SEARCH/SKIP Go to the next title/chapter/track or go back to the previous title/chapter/track. -
Page 14: Front Panel Display
Connects the input of external equipment using an S-Video cable. 11. COMPONENT VIDEO OUT Connects to equipment having Component video output. The Antenna connection does not pass ■ output signal of DVD. To watch a DVD on NOTE your TV, you must connect audio/video cables. -
Page 15: Tour Of The Remote Control
12. TITLE LIST/DISC MENU Button Use this to enter the View Recording list/Disc menu. 13. ANYKEY Button Use this to view the status of the disc that is being played. 14. REC Button Use to make a recording on DVD-RW/-R discs. -
Page 16: Connecting & Setting Up
Connecting HDMI/DVI to a TV ...21 Connecting to AV3 IN, DV input jack...22 - English Quick Overview A Quick Overview presented in this guide will give you enough information to start using the DVD Recorder. Connecting the DVD Recoder †... -
Page 17: Connecting The Dvd Recorder
1. Connect the RF cable as shown. 2. Connect one end of the SCART cable to the AV1 socket on the rear of the DVD Recorder. 3. Plug the other end into the appropriate connector on the television. -
Page 18: Other Type Of Connecting The Video Output Cable
Other type of connecting the Video output cable There are several ways to output video signal not using scart cables. Select one of the following video connecting that best suits you below. Case 1 : Connecting to a Video (Composite) output ●... -
Page 19: Case 3 : Component Video Output Jacks
AUDIO OUT jacks on the DVD Recorder and AUDIO IN jacks on TV (or AV amplifier). (See pages 20-21). 3. After connecting, refer to the page 34 to 35. You will enjoy high quality and accurate colour ● reproduction images. -
Page 20: Other Type Of Connecting The Audio Output Cable
Other type of connecting the Audio output cable There are several ways to output audio signal not using scart cables. Select the audio connection that best suits you below. Case 1 : Connecting to your TV ● Case 2 : Connecting to a stereo amplifier with AV ●... -
Page 21: Case 3: Connecting To An Av Amplifier With A Digital
Case 1 : Connecting to a TV with HDMI Jack • Using the HDMI cable connect the HDMI OUT jack on the rear of the DVD Recorder to the HDMI IN jack of your TV. • Press the input selector on your TV remote control until the HDMI signal from the DVD Recorder appears on your TV screen. -
Page 22: Connecting To Av3 In, Dv Input Jack
Case 1 : Connecting a VCR, Set-Top Box(STB), DVD ● player or Camcorder to the AV3 IN jacks Case 2 : Connecting a Camcorder to the DV IN jack ● Case 1 : Connecting a VCR, Set-Top Box(STB), DVD player... -
Page 23: Case 2 : Connecting A Camcorder To The Dv In Jack
Case 2 : Connecting a Camcorder to the DV IN jack If your digital camcorder has a DV output jack, connect it to the DV input jack of your DVD Recorder. Camcorder If the input is not selected automatically, ■... -
Page 24: System Setup
Press again to exit the on-screen MENU. … … † † , œ œ √ √ Buttons Press these buttons on remote control to move the selection bar … † , œ √ to cycle through the menu options. OK Button Press this button on the remote control to confirm any new settings. -
Page 25: Plug & Auto Setup
Auto Clock 2006 MOVE RETURN • if it is : Correct, press the OK button then the date and time will be saved. If you don't press the OK button, the date and time will be saved automatically after 5 seconds. -
Page 26: Setting The Clock
Press the …† buttons to select On for the Auto Clock. DVD-Recorder Press the OK button, then the date and time will be saved. If you don’t press the OK button, it will not be saved. √ √ You must have the RF cable connected to ■ EXIT set the Auto Clock. -
Page 27: Presetting Channels With The Auto Setup Function
√ √ MOVE RETURN EXIT Press the …† buttons to select Auto Setup, then press the OK or √ button. The message “Your data will be lost. Press [OK] to continue, [MENU] to exit.” is displayed. DVD-Recorder Install No Disc Programme Auto Setup √... -
Page 28: Presetting Channels With The Manual Setup Function
- Name : Display station name automatically detected in broadcasting signal. If not detected, you can Install edit name by using …†œ √ buttons. - MFT : You can tune up the channel frequency better √ √ √ √ using œ √ buttons. -
Page 29: Setting Up The Language Options
DivX subtitle language in advance, they will come up automatically every time you watch a movie. If the selected language is not recorded on the disc, the original pre-recorded language is selected. With the DVD Recorder in Stop mode/No Disc mode, press the MENU button. -
Page 30: Ep Mode Time Setting
EP Mode Time Setting You can select one of four recording modes by pressing the REC MODE button repeatedly. EP mode is one of four REC Mode (XP,SP,LP,EP). In EP(Extended Play) mode, you can set recording time to 6 or 8 hours by this setting. -
Page 31: Automatic Chapter Creation
• A new chapter is created according to the selected recording mode. A chapter will be about 5 minutes long in XP and SP, and about 15 minutes long in LP and EP mode. Press the STOP button to stop recording. -
Page 32: Quick Recording Setting
Quick Recording Setting If this function is set to on, both the DVD Recorder and the TV will power on at the same time, which enables you to immediiatedly record a desired channel. With the DVD Recorder in Stop mode/No Disc mode, press the MENU button. -
Page 33: Audio Options
NICAM on or off. 1. On : NICAM mode 2. Off : Only set at this position to record the standard mono sound during a NICAM broadcast if the stereo sound is distorted due to inferior reception conditions. -
Page 34: Setting Up Video Output Options
Setting up Video Output Options You can enjoy high quality image through RGB or Component video connections. With the DVD Recorder in Stop mode/No Disc mode, press the MENU button. DVD-Recorder Programme No Disc Programme Scheduled Record List Setup MOVE RETURN Press the …†... -
Page 35: Setting Up The Progressive Scan
Setting up the Progressive scan If the TV supports Progressive Scan, press the P.SCAN button on the front of the DVD Recorder to enjoy. With the DVD Recorder in Stop mode, press the P.SCAN button on the front of the DVD Recorder. -
Page 36: Setting Up The Display(Video) Options
16:9 screen. (Extreme left and right side of movie picture will be cut off.) • 16:9 Wide : You can view the full 16:9 picture on your widescreen TV. Video √ √... -
Page 37: Output Selection
• 1080i : 1920 x 1080 Output Selection • Connect the DVD Recorder to your TV via HDMI or DVI cable. And set your TV's input to HDMI. • Press the P.SCAN button while the unit is in Stop mode to select the HDMI output resolution as follows: →576p →... -
Page 38: If You Forgot Your Password
Level you want, then press the OK or √ button. For example, if you select up to Level 6, discs that contain Level 7, 8 will not play. A larger number indicates that the programme is intended for adult use only. -
Page 39: About The Change Password
Setup Enter the password NUMBER RETURN EXIT 0 ~ 9 Enter the 4-digit password using the 0 to 9 buttons on the remote control. The ‘Confirm the password’ message will be displayed. Enter your password again. DVD-Recorder Change Password No Disc... -
Page 40: Before Recording
Deleting the Scheduled Record List...48 Recording the Standard Timer List ...49 - English Before Recording This DVD Recorder can record on various types of discs. Before recording, read the following instructions and select the disc type according to your preference. Recordable discs This DVD Recorder can record on the following discs. -
Page 41: Recording Formats
This function is selected only one mode in XP, SP, LP and EP modes and you can use this mode for timer recording. Recording Times... -
Page 42: About Info Button
About INFO Button The INFO function allows you to view the current status and progress of playback and recording. Depending on the disc type and status, the displayed screen may be different. Checking the available disc space (Disc Information) When recording on an used disc, make sure that there is enough disc space for recording. - Page 43 REC icon( ) is displayed on the front panel. Recording : PR 1 NICAM DUAL L To view the current status of the disc and progress of recording : Press the INFO button, the information about the disc will appear.
-
Page 44: Recording From External Equipment You Are
You can switch channels by pressing the ● ( / ) buttons while recording pauses. To stop recording Press the STOP button to stop or finish a recording in progress. When using DVD-RW/DVD-R discs, the message ● ‘Updating the disc information. Please wait for a moment.’... -
Page 45: Making A One Touch Recording (Otr)
➞ Record Mode SP (02:12) Press the INPUT SEL. button to select DV. If the input is set to DV, a playback/record menu that enables camcorder control appears on the top of the screen. The DV device is connected. MOVE... -
Page 46: Making A Timer Recording
To view the current status of the disc and progress of recording : Press the INFO button, and information about the disc will appear. DVD-RW(VR) Disc Info Disc Name Total Title Total Playlist Recordable Time 02:12 SP Protection Not Protected... -
Page 47: Flexible Recording (For Timer Recording Only)
This function is selected only one mode in XP, SP, LP and EP modes and you can use this mode for timer recording. The FR mode recording setup is the same as Timer Recording. -
Page 48: Editing The Scheduled Record List
Press the MENU button after finishing the EXIT operation. The menu screen will disappear. Deleting the Scheduled Record List Follow these directions to delete an entry from the timer record list. PDC Edit Edit √ √ Delete √ √... -
Page 49: Recording The Standard Timer List
Recording the Standard Timer List When the start time in the Scheduled record list reaches while the set is in power off, the set will be powered on and start the recording automatically. When the scheduled recording is operating, the programme being recorded will not display on TV. -
Page 50: Playback
Both the DVD recorder and the discs are coded by region. These regional codes must match in order for the disc to play. If the codes do not match, the disc will not play. The Region Number for this DVD Recorder is described on the rear panel of the DVD Recorder. -
Page 51: Playing A Disc
● If you want the DVD Recorder to play automatically ● when it is powered Off with a disc in the DVD Recorder, power on with the PLAY button. Press the STOP button to stop playback. When you stop playing disc, the DVD ■... -
Page 52: Using The Disc Menu & Title Menu
Using the Disc Menu & Title Menu Some discs contain a dedicated menu system that allow you to select special functions for the title, such as chapters, audio tracks, subtitles, film previews, information on characters, etc. For DVD-VIDEO discs Press the DISC MENU button to enter the disc menu of the disc. -
Page 53: Slow Motion Play
PLAY button. Press and hold the SEARCH ( ) button during pause, the disc will play slowly at a Slow 1 speed. If the button is released, the pause operation will resume. The speed marked in this function may be ■... -
Page 54: Using The Repeat Function
If you want to move to a desired time to ● help you find a scene. Press the ANYKEY button during playback. DVD-VIDEO Title 1/28 Chapter 00:00:01 Time Subtitle D 5.1CH Audio Repeat Angle Zoom MOVE CHANGE Press the …† buttons to select Time. - Page 55 Subtitle D 5.1CH Audio Repeat Angle Zoom MOVE CHANGE Press the …† buttons to select Repeat, then press the œ √ buttons to select Title or Chapter you want to play repeatedly. DVD-VIDEO Title 1/28 Chapter 00:00:01 Time Subtitle D 5.1CH...
-
Page 56: Selecting The Subtitle
Selecting the Subtitle Subtitle languages may not work depending on the disc type. This is only available during playback. Using the SUBTITLE button Using the SUBTITLE button Press the SUBTITLE button during playback. Subtitle Press the SUBTITLE or …† buttons to select the desired subtitle language. -
Page 57: Changing The Camera Angle
Press the OK button. The screen will be enlarged to twice the normal size. If you press the OK button again after the screen was enlarged to twice the normal size, the screen size will be enlarged to four times the normal size. -
Page 58: Using Bookmarks
- - - - - - - - -- Bookmark MOVE PLAY CLEAR Press the œ √ button to move to the next position. Press the OK button when the desired scene appears. The number 2 is displayed and the scene is memorized. -
Page 59: Using Markers
Marker N : 1 MOVE PLAY CLEAR RETURN Press the œ √ button to move to the next position. Press the OK button when the desired scene appears. The number 02 is displayed and the scene is memorized. -- -- -- -- -- -- -- --... -
Page 60: Playing An Audio Cd/Mp3
CDDA TRACK 6 TRACK 7 PLAY MODE MOVE RETURN Press the …† buttons to select the track you want to hear, then press the OK or √ button. Audio CD(CD-DA) Screen Elements TRACK 1 Title TRACK 1 TRACK 2 TRACK 3 √... - Page 61 1. Play mode icon 2. Current track (song) 3. Displays the current track(song) information. 4. Shows the operating state of a disc and a playback time corresponding to a portion that is currently played. 5. Displays the information for the folder and its tracks.
- Page 62 Buttons on the Remote Control used for MP3 playback & 1. … … † † : Selects a track (song). 2. √ √ : Plays the selected track (song). 3. OK button: Plays back the selected track (song) or displays the files in the selected folder.
- Page 63 œ √ buttons, and then press the OK button. Play Option Mode The Play Option can be used with an audio CD or MP3 in Stop mode. Press the ANYKEY button in Stop mode. The PLAY MODE window appears.
-
Page 64: Playing A Picture
To Programme Tracks You can register a maximum of 30 tracks in the playlist. Press the ANYKEY button in Stop mode. The PLAY MODE window appears. TRACK 1 Title TRACK 1 PLAY MODE TRACK 2 Repeat : Off TRACK 3 √... -
Page 65: Playing A Mpeg4
-1 If you press the PLAY button, the Slide Show Speed screen will appear. Press the œ √ buttons to set the slide show speed, then press the OK button. DVD-RW(VR) Slide Show Speed Slow Normal Fast JPEG01 MOVE PHOTO... -
Page 66: Playing The Title List
(Fast 1, Fast 2, Fast 3) In pause or step mode, press the SEARCH ( Slow Motion button on the remote control. (Slow 1, Slow 2, Slow 3) Play Press the STEP( ) button on the remote control Step Motion during playback or pause. - Page 67 OK button. The selected entry (title) will be played back. √ √ Play To view the current status of the disc and progress of playback : Press the INFO button, the information about the disc will appear.
- Page 68 5. Recording length (i.e., the playing time) 6. Title list edit items Play: Plays the selected entry. Rename: Renames the title of a selected entry. Delete: Deletes the selected entry from the list. Edit: Deletes a section of titles. Protection: Locks or unlocks the selected entry.
-
Page 69: Editing
● A title is a section of recorded video and audio. Title List shows a list to help you select a title. Since the title list consists of the information on stream that is actually recorded, if one title is deleted, that title cannot be played again. -
Page 70: Basic Editing (Title List)
Basic Editing (Title List) Renaming(Labeling) a Title Follow these instructions to rename a title list entry, i.e., to edit the title of a recorded programme. Using the TITLE LIST button Using the TITLE LIST button Press the TITLE LIST button. -
Page 71: Locking(Protecting) A Title
Locking(Protecting) a Title Follow these instructions to lock an entry to protect it from accidental deletion. Using the TITLE LIST button Using the TITLE LIST button Press the TITLE LIST button. The Title List screen is displayed Using the MENU button Press the MENU button. -
Page 72: Deleting A Section Of A Title
With DVD-R, titles are only deleted from ■ the menu however, the Title remains physically on the disc. - English Deleting a Section of a Title Follow these instructions to delete a section of a Title List entry. Title List Length Edit 00:00:21 √ √... - Page 73 Press œ √ buttons to select Yes, then press the OK button. The selected section has been deleted. To return to the Title List screen, press the œ √ buttons to select Return. The length of the section to be deleted ■...
-
Page 74: Advanced Editing (Playlist)
The yellow-coloured selection bar moves to the ● End item. Select the starting point of the section from ● which you want to create a new scene using the playback related buttons ( - English Press the OK button at the end point. DVD-Recorder... -
Page 75: Playing Entries In The Playlist
Press the …† buttons to select Play, then press the OK button. √ √ Play (VR mode) To view the current status of the disc and progress ● of playback : Press the INFO button, and the information about the disc will appear. -
Page 76: Renaming A Playlist Entry
INFO button twice. √ √ √ √ Press the …† œ √ buttons to select Save, EXIT then press the OK button. The changed title is displayed in the title field of the selected playlist entry. DVD-RW(VR) Dolphin Length Edit √ √... -
Page 77: Editing A Scene For The Playlist
Editing a Scene for the Playlist Follow these instructions to edit scenes for a playlist. With the DVD Recorder in Stop mode, press the PLAY LIST button. The Edit Playlist screen is displayed. Edit Playlist DVD-RW(VR) Science Title Length Edit... - Page 78 Modifying a Scene (Replacing a Scene) To setup, follow steps 1 to 3 in page 77. Press the …† œ √ buttons to select the scene you want to modify, then press the OK button. DVD-Recorder DVD-RW(VR) Scene No. 2 / 7 Playlist No.
- Page 79 Moving a Scene (Changing the Position of a Scene) To setup, follow steps 1 to 3 in page 77. Press the …† œ √ buttons to select the scene you want to move (change the position), then press the OK button.
-
Page 80: Copying A Playlist Entry To The Playlist
04 00:00:20 05 00:00:03 06 00:00:11 MOVE RETURN The section you want to add is inserted prior to the ● scene selected in step 4. Deleting a Scene To setup, follow steps 1 to 3 in page 77. Press the …† œ √ buttons to select the scene you want to delete, then press the OK button. -
Page 81: Deleting A Playlist Entry From The Playlist
You can create up to 999 scenes on one ■ disc. In some cases, this may be different NOTE from the actual numbers. Press the MENU button after the ■ operation has finished. The Edit Playlist screen will disappear. Deleting a Playlist Entry from... -
Page 82: Disc Manager
Disc Manager Editing the Disc Name Follow these instructions to give a name to a disc. With the DVD Recorder in Stop mode, press the MENU button. DVD-Recorder DVD-RW(VR) Title List Title List Playlist Disc Manager Programme Setup MOVE RETURN Press the …†... -
Page 83: Disc Protection
Disc Protection Disc Protection allows you to protect your discs from being formatted or deleted due to unintended operations. With the DVD Recorder in Stop mode, press the MENU button. DVD-Recorder Title List DVD-RW(VR) Title List Title List √ √... -
Page 84: Delete All Title Lists
Setup When Protected Entry exists: The Delete All Title ● List function will not operate. If there is a title containing a still picture, however, that function will not operate. If you want to delete a protected entry, disable Protect for it on the Lock item. -
Page 85: Finalising A Disc
Finalising a disc After you record titles onto a DVD-RW/DVD-R disc with your DVD recorder, it needs to be finalised before it can be played back on external devices. With the DVD Recorder in Stop mode, press the MENU button. -
Page 86: Unfinalising A Disc (V/Vr Mode)
Disc Format : DVD-VR Disc Manager Disc Finalize Programme Setup MOVE RETURN If you select Yes, you will be prompted again with the message “Disc will be unfinalised. Do you want to continue?”. DVD-Recorder Disc Manager DVD-RW(VR:F) Title List Disc Name : Disc... -
Page 87: Additional Information
Checkpoint 2 settings correctly? Check the free space on your Checkpoint 3 DVD-RW/DVD-R discs. I pressed the REC button but there is no response. Recording is possible for DVD-RW/ Checkpoint 1 DVD-R discs only. If a programme is copy protected, it cannot be recorded. - Page 88 Cannot change the aspect ratio. The aspect ratio is fixed for DVD discs. Checkpoint 1 (See page 36) - English The angle operation does not work while playing a DVD disc. The angle operation is available only Checkpoint 1 when the disc contains images captured from different angles.
-
Page 89: Timer Recording
Video The disc revolves, but no image or bad quality images are displayed. Be sure that the Video Setting is Checkpoint 1 properly set. (See pages 34-36) Check whether there is damage to or Checkpoint 2 any foreign material on your disc. -
Page 90: Remote Control Unit
(Note that this function is possible only when no disc is inserted.) Is it possible to change a subtitle and an audio sig- nal on a recorded disc? A recorded disc is played with only the... -
Page 91: Specifications
Composite Video : Video output jack x 1 S-Video output x 1 (Y:1,0Vp-p, C:0,286Vp-p at 75Ω load) Component output x 1 (Y: 1,0Vp-p, Pb: 0,70Vp-p, Pr: 0,70Vp-p at 75Ω load) HDMI/DVI output x 1 (576p, 720p, 1080i) Video : Composite, RGB Audio: analogue... - Page 92 However, Samsung Authorised Dealers and Authorised Service Centres in other EC Countries will comply with the warranty on the terms issued to purchasers in the country concerned. In case of difficulty, details of our Authorised Service Centres are available from: Samsung Electronics U.K.
- Page 93 Contact SAMSUNG WORLD WIDE ¤ Region Country Customer Care Centre Web Site...
- Page 94 (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
