Norco 81036 Setup, Operating, Maintenance Instructions

1 ton capacity under hoist hydraulic jack

Advertisement

MODEL 81036 1 TON CAPACITY UNDER HOIST HYDRAULIC JACK
SETUP • OPERATING • MAINTENANCE INSTRUCTIONS
Note: Revision letters (A, B, C, D etc.) after model numbers have been omitted as they do not affect the setup,
operating and maintenance instructions of a particular jack unless otherwise noted.
IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING
BEFORE USING THIS DEVICE, READ THIS MANUAL
COMPLETELY
AND
THOROUGHLY,
OPERATING
PROCEDURES,
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE ACCIDENTS RESULTING IN SERIOUS OR FATAL
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
The use of portable automotive lifting devices is subject to certain
hazards that cannot be prevented by mechanical means, but
only by the exercise of intelligence, care, and common sense. It
is therefore essential to have owners and personnel involved in
the use and operation of equipment who are careful, competent,
trained, and qualified in the safe operation of the equipment and
its proper use. Examples of hazards are dropping, tipping, or
slipping of motor vehicles or their components caused primarily by
improperly securing loads, overloading, off-centered loads, use on
This jack is intended to lift, lower or support vehicle
components under the vehicle. Do not use to support or
stabilize a vehicle.
Do not exceed rated capacity.
Center load on saddle. Do not use saddle's locating lugs to
support the load.
Do not shock load.
Make sure the detent pin is fully engaged before load is applied
to jack.
Inspect the jack before each use. Do not use the jack if it
1.
The bottom of the lifting tube includes a hex head bolt which
must be backed off so the minor diameter of the jack ram can slide
into the bottom of the lifting tube. Place the round jack base flat
on the floor. Slide the lifting tube over the ram and secure them in
place by tightening the hex head bolt.
2.
A detent pin is connected to the top of the lifting column by way
of a wire lanyard. Install the detent pin in the hole on the telescopic
saddle tube closest to the saddle. Allow the exposed ends of the
detent pin to rest on the lifting tube.
3.
Sometimes air gets trapped in the hydraulic system during
shipment. An air bound hydraulic system feels spongy when
pumped and sometimes the jack will not pump in full incremental
strokes.
PROFESSIONAL LIFTING EQUIPMENT
UNDERSTAND
SAFETY
WARNINGS AND
WARNING
®
other than hard level surfaces, and using equipment for a purpose
ITS
for which it was not designed.
It is the responsibility of the owner to make sure all personnel read
this manual prior to using this device. It is also the responsibility of
the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual is lost or not legible,
contact Norco Industries, Inc. for a free replacement. If the operator
is not fluent in English, the product and safety instructions shall be
read to and discussed with the operator in the operator's native
language by the purchaser/ owner or his designee, making sure
that the operator comprehends its contents.
This product is covered by a Limited Lifetime Warranty. For details
see the back cover of Norco's product catalog.
is damaged, excessively worn, altered, modified or in poor
condition. Take corrective action before using the jack.
Adequately support the vehicle before starting repairs.
Before supporting the vehicle component with this jack refer
to the vehicle's service manual or inquire from the vehicle
manufacturer the recommended under hoist jack support
surface(s) on the vehicle component.
Be sure vehicle, vehicle component and under hoist jack setup
are stable.
Use only on a hard level surface.

SETUP

PURGING AIR FROM THE HYDRAULIC SYSTEM
a.
The release valve is activated by stepping on the foot
treadle. Stepping on the right of the treadle closes the
release valve for pumping and stepping on the left of the
treadle opens the release valve for lowering the load. Step
on the left of the treadle while simultaneously using one
hand to pump the foot pedal about ten full strokes.
b.
Release your foot from the foot treadle and pump the jack
until the ram is extended to maximum height.
c.
If the condition remains, repeat steps "a" and "b" until all the
air is purged from the system.
