MODEL 72200 22 TON CAPACITY AIR/HYDRAULIC AXLE JACK
SETUP • OPERATING • MAINTENANCE INSTRUCTIONS
Note: Revision letters (A, B, C, D etc.) after model numbers have been omitted as they do not affect the setup,
operating and maintenance instructions of a particular jack unless otherwise noted.

IMPORTANT: READ THESE INSTRUCTIONS BEFORE OPERATING

BEFORE USING THIS DEVICE, READ THIS MANUAL
COMPLETELY
AND
THOROUGHLY,
OPERATING
PROCEDURES,
MAINTENANCE REQUIREMENTS. FAILURE TO DO SO COULD
CAUSE ACCIDENTS RESULTING IN SERIOUS OR FATAL
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
The use of portable automotive lifting devices is subject to certain
hazards that cannot be prevented by mechanical means, but
only by the exercise of intelligence, care, and common sense. It
is therefore essential to have owners and personnel involved in
the use and operation of equipment who are careful, competent,
trained, and qualified in the safe operation of the equipment and
its proper use. Examples of hazards are dropping, tipping, or
slipping of motor vehicles or their components caused primarily by
improperly securing loads, overloading, off-centered loads, use on
• Before lifting a vehicle, refer to the vehicle's service manual or
inquire from the vehicle manufacturer the recommended jack lifting
points and jack stand support surfaces on the vehicle chassis.
• Inspect the jack before each use. Do not use the jack if it is
damaged, altered, modified, in poor condition, leaking hydraulic
fluid, or unstable due to loose hardware. Take corrective action
before using the jack.
• This jack was designed for lifting purposes only. Do not attempt to
work on the vehicle until jack stands rated equal to or greater than
the rated capacity of the jack are positioned to support the load.
1. Refer to the exploded view parts drawing for identification,
location and position of parts.
2. Remove the bolt and washer from under the handle fork. Insert
the handle tube in the handle fork while simultaneously inserting
the stopper rod in the handle fork guide holes.
3. Raise the lock lever on the handle assembly up so the stopper
rod does not have to come in contact with the handle fork bracket.
Rotate the release knob at the top of the handle back and forth
until you feel the bottom of the handle engage the slotted release
valve fitting inside and at the bottom of the handle fork.
4. Align the handle fork hole that accepts the bolt and washer
with the receiving hole in the bottom of the handle. Once the holes
are lined up secure the handle to the handle fork with the bolt and
washer provided.
5. Move the handle assembly up and down while simultaneously
pushing down on the lock lever until the stopper rod engages one
of the locating holes in the handle fork bracket. There are three
holes in the handle fork bracket that are used to lock the handle in
either a horizontal, angular or almost vertical position.
PROFESSIONAL LIFTING EQUIPMENT
UNDERSTAND
SAFETY
WARNINGS AND

WARNING

®
other than hard level surfaces, and using equipment for a purpose
ITS
for which it was not designed.
It is the responsibility of the owner to make sure all personnel read
this manual prior to using this device. It is also the responsibility of
the device owner to keep this manual intact and in a convenient
location for all to see and read. If the manual is lost or not legible,
contact Norco Industries, Inc. for a free replacement. If the operator
is not fluent in English, the product and safety instructions shall be
read to and discussed with the operator in the operator's native
language by the purchaser/ owner or his designee, making sure
that the operator comprehends its contents.
This product is covered by a Limited Lifetime Warranty. For details
see the back cover of Norco's product catalog.
• Do not move or dolly the vehicle while on the jack.
• Do not use the jack beyond its rated capacity. Lift only dead weight.
• Never lift a load without using a Norco approved saddle inserted in
the extension screw.
• Center load on saddle. Be sure setup is stable. Off-center
loads can cause jack failure and/or loss of load.
• Use the jack on a hard level surface.
• Do not modify the jack or use saddle adapters or saddle
extenders unless approved or supplied by Norco.
• Always lower the jack slowly and carefully.

SETUP

6. Install the quick disconnect of your choice in the back of the
air valve. The air valve and hose are equipped with a loop that
secures them to the "L" shaped hook on the upper portion of the
handle.
7. Secure the air valve and hose to the handle and connect a
shop air line to the air valve.
8. Sometimes air gets trapped in the hydraulic system during
shipment. An air bound hydraulic system feels spongy when
pumped.

PURGING AIR FROM THE HYDRAULIC SYSTEM

a. Open the release valve by turning the knob at the top of the
handle in a counterclockwise direction two full turns.
b. Depress the air valve for about 15 to 20 seconds.
c. Close the release valve by turning the knob in a clockwise
direction until tight.
d. Depress the air valve until the ram raises to maximum
height.
e. If the condition remains, repeat steps "a" through "d" until all
the air is purged from the system.
WARRANTY
