Josef Kihlberg JK10-680
7
Before all maintenance tasks on the
stapler always first disconnect it from
the air supply.
7.1 CLEANING THE STAPLER
This stapler does not require special servicing. It only
needs regular cleaning with a non-aggressive (non-
corrosive) cleaner agent. Do not remove any parts for
cleaning purposes!
Check the proper functioning of all safety
devices daily. Make especially sure that:
– the trigger works smoothly, the door stays in place
and the magazine lid does not open itself.
– all screws and nuts are securely tightened.
– the stapler is regularly lubricated (refer to chapter
5.2).
7.2 REMOVING JAMMED STAPLES
To remove a staple which has become jammed:
– Push the magazine trigger to release the catch and
pull the inner rail all the way out.
– Remove any staple remnants inside the magazine
and push the inner rail in until it clicks in behind the
catch.
8
PREVENTIVE AND CORRECTIVE MAINTENANCE
Fig. 5
