Adc Calibration; White Balance Adjustment - TCL LCD32E9A-MS91 AP Service Manual

SET FAC CH DO
Power on LAST
PVR UPGRADE DO
VERSION
PVR VERSION
ADC calibration：
Item Default
SOURCE
R OFFSET 127
G OFFSET 127
B OFFSET 127
R GAIN 127
G GAIN 127
B GAIN 127
AUTO TUNE

WHITE BALANCE adjustment:

Item Default
SOURCE AV1
Preset the channel list of factory to provide convenience
for production.
STB: The set will turn to standby mode when switch on.
LAST：remember the status of last switch off.
ON: power on when switch on.
Display the version of software.
Description
Current source
R offset, manually adjustable. Should not be changed
after automatic adjustment.
G offset, manually adjustable. Should not be changed
after automatic adjustment.
B offset, manually adjustable. Should not be changed
after automatic adjustment.
R gain, manually adjustable. Should not be changed after
automatic adjustment.
G gain, manually adjustable. Should not be changed after
automatic adjustment.
B gain, manually adjustable. Should not be changed after
automatic adjustment.
Before calibration, first, please input
corresponding pattern according to the
instruction at the bottom of the menu. Second,
select AUTO TUNE, Then press vol- button in remote
control to calibrate ADC automatically. The result will
be displayed.
Description
current source. Only AV1, HDTV, VGA need be
adjusted.
OK
OK
OK
OK
OK
Status
OK
OK
OK
OK
OK
OK
OK
OK
Status
OK
