TCL LCD32E9A-MS91 AP Service Manual page 10

COLOR TEMP NORMAL
R GAIN 129
G GAIN 128
B GAIN 126
R OFFSET 126
G OFFSET 126
B OFFSET 128
H
ow to access to R&D Menu?
1. Firstly, in TV mode, press MUTE button of remote control to mute the set.
Secondly, press MENU button to enter user main menu. Then choose CONTRAST item in
PICTURE menu and press 1,9,5,0 buttons in series. R&D Menu will appear in the left
top of screen.
2. Press RETURN button when Design Menu->DESIGNKEY is enabled (ON).
3. Press MENU button of remote control under FM.
R&D Menu(RDM)
Item Default
DESING KEY OFF
FAC MENU
SHOP INIT
OTHERE
SERVICER
MENU
NORMAL/COOL/WARM
R offset, manually adjustable. Should not be changed
after automatic adjustment.
G offset, manually adjustable. Should not be changed
after automatic adjustment.
B offset, manually adjustable. Should not be changed
after automatic adjustment.
R gain, manually adjustable. Should not be changed
after automatic adjustment.
G gain, manually adjustable. Should not be changed
after automatic adjustment.
B gain, manually adjustable. Should not be changed
after automatic adjustment.
Description
Shortcut key control switch of Design Menu
(ON: enable, OFF: disable)
To enter Factory Menu
Should not be adjusted by factory.
Other settings.
Product information
OK
OK
OK
OK
OK
OK
OK
Status
OK
OK
OK
NG
NG
