SERVICE MANUAL LCD2326LV 1. Caution………………………………………………….2 2. Specification…………………………………………….6 3. BOM List………………………………………………10 4. Alignment Procedure………………………………….18 5. Block Diagram………………………………………..24 6. Schematic Diagram……………………………………25 7. Explode View Diagram………………………………..39 This manual is the latest at the time of printing, and does not include the modification which may be made after the printing, by...
SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
Page 3
SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
Page 4
SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
Page 5
SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
2.Product Specification Spec. and Features LCD2326LV MasterData Customer Id Version Status Locked 12NC Brand Panel (1st design in TFT Panel) supplier(1st design in, optional) 0.3915mm X 0.3915mm +Pixel Pitch +Pixel Format vertical stripe RGB pixels +Panel Format 15:9 +resolution 1280*768...
Page 7
Spec. and Features LCD2326LV +input resolution: up to WXGA@60 +VGA input +DVI input auto w/"out of range" indication +PC Synch +PC Control Sound 5Wx2 +speaker max. Power 2x2W(max.) +RMS Power output( Internal) +RMS Power (External) +Music Power output( Internal) 2x4W...
Page 8
Spec. and Features LCD2326LV +Out Cinch Audio Stereo +Out Cinch Audio Mono +Out Cinch Dolby Surround 1 (DC in Jack) +Power in Cinch +Dig Audio Out +Loudspeakers internal D-Sub 15 for S/W upgrading +Control Busses +Feature Slot +ITV Smart Port +Terr.
Page 9
Spec. and Features LCD2326LV Miscellaneous +EAN Indication +Approbation for assembly by order +Tests for assembly by order +Local Integration Various Perf. Param. +Service Call-Rate PIP/POP +Type +Features Built-in Digital TV Reception +ATSC Tuner +DVB-S/C/T Tuner +Transmission Built-in Data System +Text Standard...
Page 11
LOCATION ITEM SPEC. QTY. 55-707550-3HA1A FRONT CABINET 56-707460-0HC1A LENS 56-707590-0HA1A PUSH BOTTON 56-707600-0HA1B POWER KNOB 57-10654X-00F TWIST TIE NY66 58-708810-0UI1A INLAY FOR PUSH BUTTON 58-708840-1UI INSULATED SHEET 63-B30080-BT4 S/T SCREW B 3 X 8 BT FOR SPEAKERS 63-B30080-BT4 S/T SCREW B 3 X 8 BT FOR IR RECEIVER BD 63-B30080-BT4 S/T SCREW B 3 X 8 BT...
Page 12
LOCATION ITEM SPEC. QTY. 09-RLZ12B-DTX SMD. DIODE RLZ12B 10-1N5820-F0X DIODE 1N5820 11-0BC327-CBX TRANSISTOR BC327-40 12-BC847C-0BX SMD.TRANSISTOR BC847C 12-BT3904-0BX SMD. TRANSISTOR MMBT3904LT1(NPN) 12-BT3906-0BX SMD. TRANSISTOR MMBT3906LT1(PNP) 13-0024LC-21B IC 24LC21-SOIC8 13-0LM259-6SB IC LM2596(TO-263) 13-1117MP-18B IC LM1117MPX-1.8 13-63LVDM-83B IC THC63LVDM83R 13-74HC12-3DB IC 74HC123D 13-EF4052-BTB IC HEF4052BT(D) 13-EL1883-ISB...
Page 17
LOCATION ITEM SPEC. QTY. 62-719410-0HA1A THE END AV BRACKET 63-B30120-AB3 S/T SCREW B 3.0 X 12 FOR FRONT & REAR CABINET 63-W30100-AB4 S/T SCREW W 3 X 10 AB FIX AXES SUPPORT TO REAR CABINET 63-W30100-AB4 S/T SCREW W 3 X 10 AB FIX WALL BRACKET TO REAR CABINET 64-B30060-103 M/C SCREW B 3 X 6...
4. ALIGNMENT PROCEDURE Flowchart of alignment procedure 1. Checking the Downloading 3. Initializing the 4. Checking in all PCB BD. and software EEPROM input modes supply voltages the product line of ICs 6. Downloading 7. Setting in the 5. Adjustment of the DDC data White Balance Factory mode...
Page 19
“PK26” and “Character” items. If red “Failed” is displayed after one of them, it means failed, then please return to step 3 to repeat again. Click “Write Flash” and then click “Browse” to display a dialog box. Select the target file and open it.
Page 20
4. Checking in all input modes: In TV mode: In AV/S-VIDEO/YCbCr mode: In YPbPr mode Applying the following signal modes and check whether the picture is normal: 480P-60Hz 576P-50Hz 720P-60Hz 1080i-60Hz In VGA mode: Apply the following signal modes and check whether the picture is normal: 640 x 480, 60Hz 720 x 400, 60Hz 800 x 600, 60Hz...
Page 21
Then set the parameters as below: Serial Port Setting Color temperature COM Port: COM1 √ Band Rate: 19200 5000K √ Parity: None 6500K √ Data bits: 9300K Stop bits: Click “Color temperature ignition” key in the dialog box to initialize the color temperature. Set Chroma2225 to Timing: 1027x768, 60Hz and Pattern: Gray Scales.
Page 22
Select “Edid Table” item, and click “Read” button. Then a dialog box is pop-up. Select TTE1726_ANALOG file and open it. Click “Write edid” to load the data. After the bar is full, the loading is successfully completed. If the hint “Check is error! Try again!” is pop-up, the loading is failed and check the connector, then repeat the steps again.
Page 23
LCD-BRT Brightness LCD-CON Contrast R Gain G Gain B Gain In PW1308 Factory Mode: Register Default Description UOC hpos Horizontal Phase UOC Calibration Auto adjustment of White Balance Panel LG23WXGA01 Specification of panel...
