SERVICE MANUAL
1
Caution
2
Specification
3
BOM list
4
Alignment Procedure
5
Schematic Diagram
6
Explode View Diagram
This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product
LCD32V8SY
2
6
9
16
19
33
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TCL LCD32V8SY
Summary of Contents for TCL LCD32V8SY
- Page 1 SERVICE MANUAL LCD32V8SY Caution Specification BOM list Alignment Procedure Schematic Diagram Explode View Diagram This manual is the latest at the time of printing, and does not include the modification which may be made after the printing, by the constant improvement of product...
- Page 2 SCHNEIDER ELECTRONICS GMBH-GERMANY 1. CAUTION CA UTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UT ION : T O RE DUCE TH E RIS K OF CA U T ION ELECTR ICA L SHOCK, DO NOT RE MOVE COVER (OR BACK).
- Page 3 SCHNEIDER ELECTRONICS GMBH-GERMANY IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Sa ve these instructions for later use . Follo w all W arnings and Instructions marked on the audio equipment. 1. Read Instructions-All the safety and operating instructionsshouldbe read before the productis operated. 2.
- Page 4 SCHNEIDER ELECTRONICS GMBH-GERMANY PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
- Page 5 SCHNEIDER ELECTRONICS GMBH-GERMANY OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label.If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
- Page 6 2. SPECIFICATION RELEASE LCD 32V8SY 32' LCD Widescreen HDTV Monitor Benefits Features Capable of viewing digital TV signals(480p,720p,1080i)in Widescreen High Definition TV Monitor with 1366*768 High 720progressive lines,Lightening fast response time yields Resolution Panel and Lightening Fast 16ms Response Time crisp,clear,detailed images.
- Page 7 2. SPECIFICATION RELEASE Technical Specifications LCD32V8SY PICTURE SIGNAL FORMAT CAPABILITY Panel Size(inch) Component Video Format Y,Pb/Cb,Pr/Cr: 480i,480p,720p,1080i@50Hz/60Hz Category LCD TV DVI Video Format (720p,1080i)@50Hz/60Hz Aspect Ratio 16:9 HDMI Video Format Color Temperature Adjustable(Normal/Cool/Warm) PC Compatibility VGA: Up to 1280*1024 @75Hz...
- Page 8 3. BOM LIST PART NO. SEPC LOCATION V8-L32PS1-01D01 SOFTWARE CODE U018 V8-L32PS1-01D02 SOFTWARE CODE U001 V8-L32PS1-01M01 SOFTWARE CODE U503 V8-L32PS1-07F01 ASS'Y - SOFTWARE U020 09-0BAV70-ATX SMD DIODE BAV70 D514 09-55C5V1-DTX SMD.DIODE BZV55-C5V1 D506 09-FM5817-STX SMD.DIODE FM5817 D513;D510;D512;D511 09-LL4148-ATX SMD. SWITCHING DIODE LL4148 D505;D516;D507;D508;D509;D501;D504;D503 10-HS18VC-DBX DIODE 500MW 18HSC...
- Page 9 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C617;C606;C634 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C527;C642;C530;C532;C533;C534;C531;C555 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% C577;C565;C558;C562;C506;C516;C529;C528 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% C632;C633;C547;C549;C636;C637 25-BCB101-M1X CAP. ELEC 100 UF 16V +/-20% C560;C563;C566;C569;C571;C556;C603;C600 25-BCB220-M1X CAP.
- Page 10 67-387200-3A0 HEAT SINK FOR U505 71-268390-0A0AF LABEL (QC) GREEN 71-BAR005-XX0 LABEL BAR CODE 55-718510-0HA5C BASE 57-702250-0HD HOST FOOT PAD 63-B40100-AB4 S/T SCREW B 4 X 10 AB 12 base armor plate to base cover 64-B40100-102 M/C SCREW B 4 X 10 base armor plate to base support 64-F40200-102 MACHINE SCREW F4X20...
- Page 11 19-AB0332-JTX SMD RES 3.3K OHM 1/10W 0603 R140;R171;R168;R150;R131;R122 19-AB0391-FTX SMD. RES 390 OHM 1/10W +/-1% 0603 R112 19-AB0392-JTX SMD. RES 3.9K OHM 1/10W +/-5% R135;R136;R220;R219 19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 R138;R139;R117;R099;R087;R085;R083;R081 19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603 R075;R134;R123;R124;R121;R120;R119;R118 19-AB0470-JTX RES SMD 47 OHM 1/10W +/-5%0603...
- Page 12 33-GLN121-NTX CHIP BEAD 120 OHM +/-25% L020A;L014A;L013A;L001A;L017A;L019;L026 33-GLN121-NTX CHIP BEAD 120 OHM +/-25% L028;L001;L020;L018;L014;L016A;L018A 33-KLN121-NTX CHIP BEAD 120 OHM +/-25% L023;L022;L021;L012;L011;L010 33-KLN181-NTX SMD BEAD CHIPHB 180 OHM R141;R142 33-KLN601-NTX CHIP BEAD 600 OHM +/-25% L032;L031;L030 40-D32V6N-DIC4X P.C.B.DIGIBOARD 45-OSC14M-3Y2 CRYSTAL 14.31818MHZ Y001 45-OSC27M-0Y3 CRYSTAL 27MHZ...
- Page 13 56-718290-0HA5C PUSH BUTTON 56-718330-0HC5Z LENS 56-718570-0HA5C POWER KNOB 63-B30100-AB4 S/T SCREW B 3 X 10 AB 12 FOR RCA 63-B30100-AB4 S/T SCREW B 3 X 10 AB MTG FRONT CTL BD & FRONT CABINET 63-B40150-AB3 S/T SCREW B 4 X 15 AB (BLACK) 12 MTG BRACKET&...
- Page 14 72-32V8SY-S139A OPERATION MANUAL 74-026035-6WE9B POLYBAG 74-110085-50G9B PALSTIC BAG 75-813420-CC0 POLYFOAM"UL" 75-813430-CC0 POLYFOAM"UR" 75-813440-CC0 POLYFOAM"LL" 75-813450-CC0 POLYFOAM"LR" 75-813460-CC0 POLYFOAM"LL" 75-813470-CC0 POLYFOAM"LR" 76-813480-0AT9C CARTON BOX 55-718080-0HA1A FRONTPANEL 55-718500-0HN1C REAR CABINET 58-32V8MP-0UI9A INLAY MODEL NO. 58-718040-0UI1F INLAY 58-718040-0UI1G INLAY 63-B40150-AB3 S/T SCREW B 4 X 15 AB (BLACK) 25-DFB229-M1X CAP.
- Page 15 25-BFB220-M1X CAP. ELEC 22 UF 50V +/-20% C713 25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20% C714 28-BB0103-ZFX SMD CAP. 0.01 UF 50V F 0805 C707 28-BB0104-ZFX SMD CAP. 0.1 UF 50V +80/-20% 0805 C701;C709;C711;C712;C715;C717;C719 28-BB0334-ZFX SMD. CAP 0.33UF 50V +80%/-20% C724 28-BB0470-JCX SMD CAP.
- Page 16 4. ALLIGNMENT PROCEDURE 1 Scope AFC031A chassis is developed for America market which supports 1 analog RF input,1 VGA input, 1 DVI input,1 compenent input,1 Video input,1 S-Video input. 2 Alignment content and method 2.1 How to enter the Factory Menu 2.1.1 press “vol-”...
- Page 17 4.6.4 select YUVcalbr and press ok on RC 4.6.5 input the special pattern(attached figure2),select Y/G Offset in ADCBal sub-menu calibration to j- ust see 6 level grays 6grays Figure2 grays pattern 4.6.6 select Y/G Gain calibration to just see 6grays,figure3.
- Page 18 Figure3 grays pattern 6grays 4.6.7 input Chroma2327 30IRE gray pattern,format 720p60Hz; 4.6.8 select R/G/B Offset calibration,target is (x,y)=(285,294) 4.6.9 input 100 IRE gray pattern,selection R/G/B Gain calibration,target is (x,y,Y)=(285,294,260~280 nit) 5 in case reloading the system software,it is necessary to enter factory menu to Reset data...
- Page 28 GVCK...
