Meter Components
Changing the Battery
The LCD will show an empty battery icon when it is time to change
the battery. Remove the screw cover of the battery compartment by
rotating counter clockwise. A coin may be required to loosen the
cover. Gently pry out the old battery with a small knife or tiny screw-
driver as shown below, being careful not to damage the battery
holder. Replace with a new CR2032 lithium coin cell battery and
replace the screw cover. Tighten the cover clockwise until the o-ring
seal is slightly compressed.
WARNING: Battery can explode or leak and cause burns if installed
backwards, disassembled, charged, or exposed to water, fire or
high temperature.
CR2032 Battery CALIFORNIA ONLY: Perchlorate Material – spe-
cial handling may apply. See www.dtsc.ca.gov/ hazardouswaste/
perchlorate.
Sensor Cap
Light Sensor
LCD Display
POWER Button
SCAN Button
Battery Compartment
Universal Mounting Bracket
3
