P/N* 77 – XXX – X – XXX
373 5.6K CONVENTIONAL
373 5.6K CONVENTIONAL
Notes:
* Use suffix "I" for ISO 7-1 connection (e.g., 77-373-4-175-I)
** LPCB Approved Series TY-B Conventional Sprinkler as-
semblies only: Use suffix "L" for LPCB Approved assemblies
(e.g., 77-373-4-175-L or 77-373-4-175-IL for LPCB Approved
and ISO 7-1 connection)
*** Eastern Hemisphere sales only
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
SIN
TY363
1
PURE WHITE (RAL9010)***
TY3630**
3
SIGNAL WHITE (RAL9003)
4
9
TABLE A
PART NUMBER SELECTION
SERIES TY-FRB CONVENTIONAL SPRINKLERS
Ordering
Procedure
Contact your local distributor for
availability. When placing an order,
indicate the full product name and
Part Number (P/N).
Sprinkler Assemblies with
NPT Thread Connections
Specify: Series TY-FRB Conventional
Sprinkler, (specify) SIN, K=5.6, Quick
Response, (specify) temperature
rating), (specify) finish, P/N (specify,
refer to Table A)
Sprinkler Wrench
Specify: W-Type 6 Sprinkler Wrench,
P/N 56-000-6-387
SPRINKLER
FINISH
NATURAL
BRASS
POLYESTER
POLYESTER
CHROME
PLATED
TFP667
Page 3 of 4
TEMPERATURE
RATINGS
135 135°F (57°C)
155 155°F (68°C)
175 175°F (79°C)
200 200°F (93°C)
286 286°F (141°C)
