- Page 1 EAGLE BROOKE EAGLE BROOKE CONCRETE STONE TOP GAS FIREPIT TABLE ASSEMBLY INSTRUCTION ITEM#: TRS47GQ SKU#: 810398583 Need help? We are here for you! 1.877.539.7436 Call us between 9:00 AM and 4:30 PM Eastern Time Monday through Friday For further assistance.
-
Page 2: Carbon Monoxide Hazard
ASSEMBLY INSTRUCTIONS ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE. INTENDED FOR RESIDENTIAL USE ONLY. TRS47GQ WARNING: For Outdoor Use Only Installation and service must be performed by a qualified installer, service agency, or the gas supplier. WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. - Page 3 When an appliance is for connection to a fixed WARNING piping system, the installation must conform with local codes or, in the absence of local codes, with If the appliance is not in use, the gas must be turned the National Fuel Gas Code, ANSI Z223.1 NFPA off at the supply cylinder.
-
Page 4: Parts List
PARTS LIST PART MATERIAL CODE PART Q’TY 47XA4932 COVER 17C33A0706001YX TRS47GQ-CS10-3 BOLT M6*15 REAR FRAME TRS47GQ-CS04-J 17C33A0709001YX FRAME A BOLT M6*25 TRS47GQ-CS04-K 17C33A0714001YX BOLT M6*40 FRAME B TRS47GQ-CS10-9 17FA05040301-YX WASHER d6.5*D13*1.0 BOTTOM FRAME TRS47GQ-CS10-5 TRS47GQ-CS24-1 FRONT DOOR LAVA ROCKS 1404046 TRS47GQ-CS05-4 TOUCH-UP TABLE TOP... - Page 5 FIGURE 2 FIGURE 3 10 13 Step 2: Fasten the bottom frame (#4) and the cross brace (#16) to the frames (#2 and #3) by using bolts (#11), washers (#13) and screws (#17). See Figure 2. Step 3: Fasten the lower connector (#7) to the corner of the FIGURE 4 bottom rim of the frame B (#3) by using bolt (#10) and washers (#13).
- Page 6 FIGURE 6 FIGURE 7 Caution: The Tank must face this way. Rotate Plastic Clockwise Screw Step 6: Step 7: Open the front door (#5) and place the tank into the Attach the fuel supply hose (#6) to the tank by rotating bottom frame (#4).
- Page 7 WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. SPECIFIC WARNINGS: 1) Both children and adults should be aware of the hazards of high surface temperatures and should keep their distance in order to avoid burns and ignition of clothing.
- Page 8 SAFETY INSTRUCTIONS This outdoor appliance is not intended to be installed in or on recreational vehicles and/or boats. 1. Only use the regulator with hose assembly supplied with your appliance. A replacement regulator with hose assembly must be the one specified in this manual.
-
Page 9: Care Instructions
INSTRUCTIONS FOR REMOVING THE TANK FIGURE A FIGURE B Plastic Counter-Clockwise Screw Note: Step B: Close the valve tightly before removing the tank. Remove the tank from the tank-support assembly and through the tank fastener. See Figure B. Step A: Note: To remove the fuel supply hose from the tank, rotate To replace the tank, repeat Step 6 and Step 7 in the... - Page 10 CALIFORNIA PROPOSITION 65 WARNING: The burning of gas cooking fuel generates some by products which are on the list of substances known by the state of California to cause cancer, reproductive harm, or other birth defects. To reduce exposure to these substances, always operate this unit according to the use and care manual, ensuring you provide good ventilation when cooking with gas.
