E8000 tech specs
Frame
T6 heat-treated, 7005 aluminium designed for Shimano STePS e8000 motor.
Fork
Chromoly steel with tapered steerer tube.
Kickstand
Aluminium with replaceable feet.
Headset
1⅛" FSA Orbit XII , 1½" tapered 1⅛" .
Steerer arm
Chromoly steel with machined fittings and rubber covered balljoint.
Dropouts
Aluminium,machined and replaceable.
Shimano
STePS system
Motor
Bottom bracket mounted for low centre of gravity and light; 2.8kg. 250W/70Nm Torque max output.
Battery:
High capacity, 504Wh and low charging time of 4 hours; 2.62kg.
Crankset:
Hollowtech II style, 38 tooth chaining.
Shifter:
XT di2
Rear Derailleur:
XT di2
Front wheel:
Novatec hub, sealed bearings, 10mm axle, laced to Alex 36H Supra rim.
Rear wheel:
Novatec hub laced to Alex 36H Supra rim.
Cassette:
Shimano XT 11-42
Tyres:
Schwalbe Kojak 20" x 1.35', 26" x 1.35',
extra set, Schwalbe Marathon Supreme 20" x 1.6', 26" x 1.6'
Fenders:
Plastic, black.
Brakes:
Shimano Zee 4-pot disc brakes , 180mm Shimano rotors
Handlebar:
Thomson Trail, 750mm, 31.6 mm alloy riser bar, black.
Stem:
Thomson X4 50mm, black.
Stemlifter:
EasyUp 100mm of adjustment, black.
Grips:
Velo Ergo lock-on.
Bell:
Brass Japanese Wind Bell, black.
Saddle:
Original Bullitt Racing Seat from Velo, black.
Seatpost:
31.6 mm alloy, 410mm, black.
Seat clamp:
Thomson, fixed.
Front lights:
Busch Müller Lumotec IQ2 Eyc powered from main Shimano battery.
Rear lights:
Busch Müller Secula powered from main Shimano battery.
Chain:
KMC
Lock:
ABUS Amparo, ABUS Key Alike© integration with STePS battery.
Contact information
HQ – Larry vs Harry, Esromgade 15, opg. 2 (rampen), DK–2200 Copenhagen
Bullitt Store – Frederiksborggade 43, DK–1361 Copenhagen Denmark
www.larryvsharry.com
