Related Manuals for Zamel BULIK DRS-982H
Summary of Contents for Zamel BULIK DRS-982H
- Page 1 Available BUliK Chime Versions PDH-227 DRS-982H PDH-991 PDB-233 RT-236 Remove the chime from the socket outlet Remove the chime cover The chime code setting The push-button code setting The sound type selection inside the push-button...
- Page 2 (hermetic, 100 m* operating range) and PDB-233 (the reception chime, 100 m* operating range), • It is possible to increase the number of the chimes and push-buttons, if needed, • Two sounds to select (a possibility of identification of the push-button pushed), • Loudness volume control, • Optical signalling (LED) of the chime signal receiving, • The push-button with the built-in acoustic signalling, • Chime sound: DING - DING or DING - DONG, DING - DONG, • Sound level: approx. 85 dB. i. TeCHNiCAl DATA WiReleSS CHiMe BUliK DRS-982H Sound level: approx. 85 dB Coding: 16 channels Power supply: 230 VAC / 50 Hz Stand-by power consumption: 1.8 VA Maximum power consumption: 2.8 VA Transmission: radio Operating frequency: 433.92 MHz Protection class: II IP protection: IP 20 Chime sound: DING-DING or DING-DONG, DING-DONG Temperature operating range: 0°C ÷ 35°C WiReleSS, HeRMeTiC PUSH-BUTTON PDH-991 Power supply: MN21 / 23A 12 V battery Transmission: radio Operating frequency: 433.92 MHz Transmitter power output: < 5 mW...
