Process indicator with two analogue inputs, calculations and programmable analogue output

Advertisement

Quick Links

control
– motion – interface
Process Indicator with Two Analogue Inputs,
Calculations and Programmable Analogue Output
AX 345
Process Indicator, Display only
(separate manual available)
AX 346:
Process Indicator with Analogue Outputs 0 - 10 V und 0/4 – 20 mA
AX 347:
Process Indicator with 2 Presets and Optocoupler Outputs
(separate manual available)
• Two analogue inputs with independent scaling, each +/- 10V or 0/4 – 20 mA
• Operating modes for display of input A, input B as well as combinations
A + B, A - B, A x B und A : B
• Fully programmable scaling and zero definitions
• Useful supplementary functions like Tare function, programmable averaging
functions, programmable linearization etc.
• Power supply 115/230 VAC and 17-30 VDC in the same unit
• Aux. output 24 VDC / 100 mA for sensor supply
Ax34607b_e.doc / Mrz-08
AX 346
Operating Instructions
ELEKTRO-TRADING sp. z o.o
Tel.
+48 (0-32) 734-55-72
Tel/Fax +48 (0-32) 734-55-70
E-Mail et@elektro-trading.com.pl
http://www.elektro-trading.com.pl
Page 1 / 27
