Il dispositivo realizza una interfaccia che permette di visualizzare le impostazioni di protezione e lo stato di funzionamento del Megatiker elettronico
Description
The device allows for an interface which displays the protection setups and the functioning condition of electronic Megatiker.
Descripción
El dispositivo realiza una interfaz que permite visualizar la configuración de protección y el estado de funcionamiento del Megatiker electrónico.
Page 1
Istruzioni d'uso Instruction sheet PART. U1281A M7TE/2 07/06-01 Instrucciones de empleo Installazione - Installation - Instalación Terminazione “Mini B” “Mini B” plug Terminal “Mini B” Cavo USB USB cable Cable USB Interfaccia seriale USB USB Serial Interface Interfaz SCS-USB Terminazione “Tipo A”...
Page 2
VIRTUAL COM on the first COM available in the PC. If there is any doubt, in system settings check the COM No. set. Use BTicino software setting the correct COM No. Connect the interface to the switch.
