Larson Electronics LED10W-1SCB Instruction Manual

9-48VDC - 225' Spot Beam - 900 Lumen - 10 Watts
Thank you for your purchase of the Larson Electronics LED10W-1SCB.
WARNING:
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

CRITICAL SAFETY INSTRUCTIONS:

INSTALLATION SHOULD ONLY BE CONDUCTED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH NEC AND ANY
•
RELEVANT LOCAL BUILDING CODES.
RISK OF FIRE OR ELECTRIC SHOCK. FIXTURE INSTALLATION REQUIRES KNOWLEDGE OF LUMINAIRES ELECTRICAL
•
SYSTEMS. IF NOT QUALIFIED, CONTACT A QUALIFIED ELECTRICIAN.
• BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
• MAKE SURE THE SUPPLY VOLTAGE IS THE SAME AS THE RATED LUMINAIRE FIXTURES VOLTAGE.
• TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET METAL OR SHARP
OBJECTS. SUITABLE FOR DAMP LOCATIONS.
The Larson Electronics LED10W-1SCB 10 Watt LED Light with double ball joint mount and suction cup base is
recommended for various applications where a temporary and adjustable mount is desired. We have tested this suction cup
mount to speeds of 90 MPH, ensuring an ideal mounting solution for applications where a temporary but exceptionally
strong mount is needed. To attach this unit the operator simply has to press down on the light and the suction cup will
automatically attach itself to various smooth surfaces. To remove the unit a tab located at the suction cup base allows the
user to simply pull on the tab to release the cup from the mounting surface.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING THIS FIXTURE. SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. THE LED10W-1SCB MUST BE WIRED IN ACCORDANCE WITH NATIONAL ELECTRICAL CODE AND
ALL APPLICABLE LOCAL CODES. PROPER GROUNDING IS REQUIRED FOR SAFETY.
WE STRONGLY ENCOURAGE ONLY A LICENSED ELECTRICIAN INSTALL, OPERATE AND MAINTAIN THIS
PRODUCT. IF YOU ARE NOT QUALIFIED OR UNFAMILIAR WITH ANY ASPECT OF THIS INSTRUCTION SHEET,
CONSULT AN ELECTRICIAN. THERE ARE NO SERVICEABLE PARTS INSIDE.
WARNING: MAKE SURE POWER IS TURNED OFF BEFORE STARTING THE
INSTALLATION OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –
RISK OF PERSONAL INJURY –
RISK OF BURN –
ALLOW FIXTURE TO COOL BEFORE SERVICING.

Low Voltage DC

Connect power to power supply outputting low voltage between 9-42 Volts DC.
This variable voltage allows greater versatility without affecting light output. Ensure
deutsch connectors are properly connected (If applicable)

DETACHABLE CORDS

•
Cord is attached via a weatherproof 2-pin Deutsch connector.
•
The cord is detachable by depressing the tab on the top of the connectors. This enables the
operator to remove and store the light while leaving the cord connected to the power source.
•
Additional or replacement cords can be ordered from our website. Contact us or visit LarsonElectronics.com for more
information.
Larson Electronics, LLC
10 Watt LED Spotlight on Suction Cup Mount
Instruction Manual
DISCONNECT POWER AT BREAKER BEFORE INSTALLING OR SERVICING.
FIXTURE MAY BECOME UNSTABLE OR DAMAGED IF NOT INSTALLED PROPERLY.
Phone: (800) 369-6671 Fax: (903) 498-3364
LED10W-1SCB
www.larsonelectronics.com
1 of 2
