- Page 1 Ropox Support Washbasin Fixed – Basic - Manual MOUNTING INSTRUCTIONS Keep this manual with the product at all times PDF 6095 / 01.07.2019...
- Page 2 Mounting must always be carried out by competent personnel Before starting installation, check that all parts mentioned in the list of components have been delivered. See list of components from page 23. Ropox Support Washbasin is available in three models: Fixed page 3 Basic height adjustment...
- Page 3 Support Washbasin, Fixed (40-44010/11) Recommended: 6 x 8x72 6 x rawlplugs NOTE: Depending on wall type, choose other suitable screws, as required. Max load on upper screws: 150 kg/screw Mounting of covers: See page 9-11 © ROPOX 2014 Page 3...
- Page 4 Support Washbasin with Basic frame (40-4012/13) 2 x M5 2 x M5x10 12 x 4x16 © ROPOX 2014 Page 4...
- Page 5 6 x rawlplugs NOTE: Depending on wall type, choose other suitable screws, as required. Max. load on upper screws: 85 kg/screw 510,5 Fine adjustment of wall fitting – use legs on washbasin as a guide © ROPOX 2014 Page 5...
- Page 6 © ROPOX 2014 Page 6...
- Page 7 © ROPOX 2014 Page 7...
- Page 8 © ROPOX 2014 Page 8...
- Page 9 Mounting of covers for 40-44012/13 2 x 4.5x50 2 x rawlplugs © ROPOX 2014 Page 9...
- Page 10 2 x M4x10 6 x 4x16 © ROPOX 2014 Page 10...
- Page 11 © ROPOX 2014 Page 11...
- Page 12 3 x M4x10 © ROPOX 2014 Page 12...
- Page 13 Support Washbasin with Manual frame (40-44014/15) 4 x M8x20 © ROPOX 2014 Page 13...
- Page 14 © ROPOX 2014 Page 14...
- Page 15 1 x M4 Allen wrench © ROPOX 2014 Page 15...
- Page 16 1 x M8x20 © ROPOX 2014 Page 16...
- Page 17 Recommended: 6 x 8x72 6 x rawlplugs NOTE: Depending wall type, choose other suitable screws, as required. Max. load on upper screws: 71 kg/screw © ROPOX 2014 Page 17...
- Page 18 Tip: Move washbasin to top position to facilitate further mounting montagen © ROPOX 2014 Page 18...
- Page 19 1 x M5x50 © ROPOX 2014 Page 19...
- Page 20 © ROPOX 2014 Page 20...
- Page 21 Mounting of covers for 40-44014/15 1 x strips 2 x 8x72 2 x M4x10 © ROPOX 2014 Page 21...
- Page 22 6 x 4x16 © ROPOX 2014 Page 22...
- Page 23 © ROPOX 2014 Page 23...
- Page 24 3 x M4x10 © ROPOX 2014 Page 24...
- Page 25 1 (one) 40*44010-062: Fixed wall bracket, short 1 (one) 40*44010-048: Frame Basic side bracket 1 (one) Ropox Support Washbasin, Basic height adjustment, left, 40-44012: 40*44010-064: Top plate with washbasin, left-oriented 1 (one) Basic height-adjustment brackets 1 (one) set Incl. 40*44010-025...
- Page 26 Ropox Support Washbasin, Manual height adjustment, left, 40-44014: 40*44010-064: Top plate with washbasin, left oriented 1 (one) Provided with: Top frame, left oriented 1 (one) Incl. 40*44010-042 Frame Manual support, left 40*44010-057 Hand crank assembly left 30-67600: Flexi legs, Manual 2 (two) sets Incl.
- Page 27 2 (two) 40*44010-098 Drain relief 1 (one) 40-44021 Cover kit for fixed and basic, left-oriented 40-44022 Cover kit for fixed and basic, right-oriented 40-44027 Cover kit for manual, left-oriented 40-44028 Cover kit for manual, right-oriented © ROPOX 2014 Page 27...
- Page 28 Mixer tap, Damixa Clover Easy 1 (one) Incl. Transition piece 10x½” 97001101 2 (two) 40-44045 No-touch mixer tap 1 (one) Oras Electra 6250F Incl. 97001348 Oras Cu-tube 1 (one) ½”x3/8” 97001101 2 (two) 40-40935 Overflow plug 1 (one) © ROPOX 2014 Page 28...
