- Page 1 Ropox SlimLine Electric USER MANUAL This manual must always accompany the product PDF 6183 01-01-18 © ROPOX 2017...
-
Page 2: Table Of Contents
Safety in use ..............................28 Service information ............................29 Troubleshooting ............................29 Maintenance ..............................30 Performance test ............................30 Service schedule ............................31 Spare parts ..............................32 CE marking ............................... 33 EU – Declaration of confirmity ........................33 Complaints ............................... 34 © ROPOX 2017... -
Page 3: Product Information
Product information General product information Ropox Slimline height adjustable unit offers the user the greatest experience in the least possible packaging. With a depth of only 58mm the height adjustment does not take up unnecessary space in the bathroom and leaves an elegant impression. -
Page 4: Use
Ropox Slimline Electric is height adjustable in order to provide an optimal work posture for users and helpers. Ropox Slimline Electric may NOT be used as a lifting table or as a person lifter. Height adjustment with a fixed standard control Hand control with spiral cable (available for purchase) ©... -
Page 5: Dimension Drawings
Dimension drawings 40-15601 700-1000mm travel range © ROPOX 2017... - Page 6 40-15603 700-1000mm travel range © ROPOX 2017...
- Page 7 40-15605 708-1008mm travel range © ROPOX 2017...
- Page 8 40-15607 300mm travel range © ROPOX 2017...
-
Page 9: Installation Interfaces
70-100 cm (incl. washbasin). The drain may also be positioned in the floor – in that case, however, it is not possible to use the inside cover cap (40-15610). © ROPOX 2017... -
Page 10: Positioning Of Water, Drain, And Power Installations
Positioning of water, drain, and power installations The power connection is positioned in a radius of up to 1500mm © ROPOX 2017... -
Page 11: Connection Adapters
Connection adapters If the recommendations cannot be met, the components described below may be ordered. Ropox is not responsible for the optimal functionality of the below components under covers when adjusting the height of the unit. Water connection adapters Installation in room... -
Page 12: Cleaning
During use, the product may get dirty. It is very important that the washbasin and the lifting unit are cleaned in accordance with these instructions. Ropox SlimLine may be wiped with a wrung cloth with lukewarm water and a mild detergent. Do not use corrosive/grinding fluids or scouring sponges. -
Page 13: Mounting Information
List of components Slimline lifting unit with washbasin 40-15601 40*15601-040: Lifting unit 1 (one) 97002454: Mirror 600x800x5 1 (one) 40*15601-084 Cover top 1 (one) 40*15601-062 Cover bottom 1 (one) 40-15610 Installation cover* 1 (one) (Available for 40-15607) © ROPOX 2017... - Page 14 4 (FOUR) 40*15601-021 Mounting bracket 1 (ONE) 95041285 Bolt M12x85 2 (TWO) 95170512 Chamfered washer M12 2 (TWO) 97001467 Mounting parts for Ifö Spira 60 1 (ONE) 40*15601-095 Spacer 8 (EIGHT) 95020521 COUNTERSUNK INSEX screw M5x20 4 (FOUR) © ROPOX 2017...
- Page 15 40-15620 60cm Straight Support Washbasin 1 (ONE) (for 40-15601) 40-15621 Ropox Washbasin Standard 60, 1 (ONE) (for 40-15603) 40-15622 Hospital Washbasin 1 (ONE) (for 40-15605) © ROPOX 2017...
-
Page 16: Mounting Instructions
Fix the mounting bracket as illustrated on the drawing with the right distance to water and drain. Make sure that the mounting bracket is level. Hang the lifting unit on the mounting bracket. Make sure to put the M12 bolts for the washbasin in the frame prior to mounting. © ROPOX 2017... - Page 17 Push 8 (eight) spacers in behind the frame so that it has the right distance to the wall. Mark the 8 holes for fastening. Take the lifting unit down again and drill the holes in the wall. © ROPOX 2017...
- Page 18 Use suitable rawlplugs and screws for the mounting. Remove the protective foil on the tape and fasten the power supply above the unit. Locate 1.5 m above the floor measured on the underside. Place it in the middle of the lifting unit. © ROPOX 2017...
- Page 19 Connect the electrical system as illustrated. Fix the excess cable from the power supply on the mounting bracket with strips. Check that the unit freely moves at up/down. If needed, use cable clips etc. for the power cable. © ROPOX 2017...
- Page 20 Fix the rods for the mirror bracket in the frame with M5 countersunk screws. Install the siphon. Adjust the holder bracket to the right height for the washbasin you have chosen, cf. below. 40-15620: 20mm 40-15621: 40mm 40-15622: 40mm © ROPOX 2017...
- Page 21 MUST to be placed between the wash basin and the unit. It is recommended to grout around the wash basin. Now mount the washbasin with the enclosed mounting parts for bolt mounted washbasins. © ROPOX 2017...
- Page 22 That is now pushed in place so that the brackets glue to the wall. Remove the installation cover and push the brackets very firmly against the wall to make sure that the glue has good contact with the wall. © ROPOX 2017...
- Page 23 The power connection is positioned in a radius of up to 1500mm Install water connection and drain hoses as illustrated. Put the installation cover back on. Make sure that all hoses move freely and unhindered. © ROPOX 2017...
- Page 24 Put the outermost cover on as illustrated. Install the rest of the drain and screw it in the washbasin. Now check that the washbasin and hoses below the caps move freely by moving the lifting unit up and down. © ROPOX 2017...
- Page 25 Remove the protective foil on the double-coated tape on the back of the mirror and fix it as illustrated. Press it firmly and make sure that the mirror is properly fastened so that the final mirror bracket can be mounted. © ROPOX 2017...
-
Page 26: Cable Diagrams
Cable diagrams Standard product with fixed control © ROPOX 2017... -
Page 27: User Information
User information Product with fixed control and handheld control. Here a split cable is used. © ROPOX 2017... -
Page 28: Functionality Testing
4. Check that there is no load on the frame or any objects preventing its movement. 5. Check that there are no objects preventing the frame from moving freely within the height adjustment range. If the above points are observed, the Ropox Slimline is ready to use. See the section ”Safety in use”. Label Each unit has its own label as illustrated. -
Page 29: Safety In Use
Safety in use · The height adjustment of Ropox Slimline Electric may only be used by persons who have read and understood these instructions. · Ropox Slimline Electric may not be used as a lifting table or as a person lifter. -
Page 30: Service Information
Adjust the hoses so that they are not kinked/twisted. Reset: Press and hold the UP (▲) and DOWN (▼) buttons at the same time. Keep the buttons depressed for approx. 10 seconds. Now move the frame to bottom position for resetting. © ROPOX 2017... -
Page 31: Maintenance
Efter each inspection, the service schedule must be completed. See next page. Only use original Ropox spare parts as replacement parts. If other parts are used, the warranty may be void. © ROPOX 2017... -
Page 32: Service Schedule
Date: Signature: Signature: Remarks: Remarks: Service and maintenance Serial no. Service and maintenance Serial no. Date: Date: Signature: Signature: Remarks: Remarks: Service and maintenance Serial no. Service and maintenance Serial no. Date: Date: Signature: Signature: Remarks: Remarks: © ROPOX 2017... -
Page 33: Spare Parts
Standard washbasin 40-15621 Hospital washbasin 40-15622 Plumbing kit for SlimLine 40-15612 Mirror 600x800x5 97002454 Top cap 40*15601-084 Actuator 97002671 Control box 97002672 Power supply 97002679 Installation cover 40-15610 Oras Saga 3910F 97001706 Bottom cap 40*15601-062 Control 97002674 © ROPOX 2017... -
Page 34: Ce Marking
CE marking EU – Declaration of confirmity I, the undersigned, hereby declare that the following products: Ropox Slimline Electric Item no.: 40-15601 40-15603 40-15605 40-15607 are in accordance with the following directives and standards: DIRECTIVES Directive concerning medical devices 93/42/EEC (Risk class 1) Machinery Directive no. -
Page 35: Complaints
Complaints www.ropox.dk. See general terms of sale and delivery on © ROPOX 2017...
