Summary of Contents for Lancaster BBG019 087P
- Page 1 MODEL BBG019_087P VM Innovations Assembly Instructions Please mention model#VMBBG019_087P_V1 877-852-8164 www.vminnovations.com...
- Page 2 TOLL FREE: 877-852-8164 www.vminnovations.com Please be aware of your product’s Limited Warranty for the return/refund policy from the store, We, at LANCASTER, can not handle the product which is out of product’s limited warranty since we only provide available parts. Thank you!
-
Page 3: Tools Required
English TOOLS REQUIRED Phillips Screwdriver - Not Included Standard (Flat Head Screwdriver) - Not Included Wrench - Included Allen Key - Included Power Tools: Set to Low Torque RECOMMENDED Electric Screwdrivers may be helpful during assembly; however, please set a low torque and use extreme caution. -
Page 4: Parts Identifier
English PARTS IDENTIFIER PART NUMBER FIG NUMBER FOR FIG. 3 PART QUANTITY PART NAME Tube - 1 FOR FIG. 3 FOR FIG. 2 FOR FIG. 1 FOR FIG. 5 Tube - 2 Tube - 3 Tube - 4 Tube - 5 FOR FIG. - Page 5 English HARDWARE FOR FIG. 1,4,10 FOR FIG. 5 FOR FIG. 8,11 FOR FIG. 1,4,5,8,10,11 M6x30mm Bolt M6x32mm Bolt M6x42mm Bolt M6 Washer FOR FIG. 1,4,5,8,10,11 FOR FIG. 12 M6 Nut Wrench Allen Key Wing Nut PRE-INSTALLED PARTS FOR FIG. 8 FOR FIG.
-
Page 6: Before Assembly
English BEFORE ASSEMBLY Find a clean, level place to begin the assembly of your Product. Verify that you have all listed parts as shown on the part list pages. If any parts are missing, call our customer service. BEFORE ASSEMBLY Please inspect and layout all the POLES and parts BBG019_087P (Continued on the next page.) - Page 7 English ASSEMBLY FIG. 1 FIG. 2 Pre-installed BBG019_087P (Continued on the next page.) www.mdsports.com...
- Page 8 English ASSEMBLY FIG. 3 Pre-installed Pre-installed FIG. 4 BBG019_087P (Continued on the next page.) www.mdsports.com...
- Page 9 English ASSEMBLY FIG. 5 Pre-installed FIG. 6 BBG019_087P (Continued on the next page.) www.mdsports.com...
- Page 10 English ASSEMBLY FIG. 7 Pre-installed Pre-installed BBG019_087P (Continued on the next page.) www.mdsports.com...
- Page 11 English ASSEMBLY FIG. 8 Pre-installed Note: With the help of another Pre-installed adult, attachthe Backboard (#12) to the Top Tubes - 1, 2 (#1, #2). Pre-installed Note: DO NOT overtighten bolts. Note: Please do not use any bolts on the Backboard at this step. The Bolts will be added later for the Ramp Tab (See FIG.
- Page 12 English ASSEMBLY FIG. 9 Note: To secure the Ball Return Net (#13) to Tubes - 1, 2 (#1, #2), Note: Slide in the elastic straps attach the elastic straps over onto Tubes - 1, 2 (#1, #2), then the nuts as shown in FIG. 9. slide the sleeves of the Ball Return Net (#13) onto tubes at the top.
- Page 13 English ASSEMBLY FIG. 10 Note: After the elastic straps are bound to Tube 8 (#8), slide Tube - 9 (#9) into the sleeve of the Ball Return Net, then attach it to Tube - 8 (#8) as shown in FIG. 10. Fasten the Bolt (#A1) with the Allen Key to finish this step.
- Page 14 English ASSEMBLY FIG. 11 Back View Ramp Tab Note: At each bottom hole of the backboard, attach the ramp tabs on Ball Return Net (#13) using Bolts (#A3), Washers (#A4) and Nuts (#A5) as shown in FIG. 11. BBG019_087P (Continued on the next page.) www.mdsports.com...
- Page 15 English ASSEMBLY FIG. 12 Control Wire Note: Run the rest of the Control Wire through the loops on the Ball Return Net (#13). Place the Control Wire on the Tube - 8 (#8) using the Self-Stick Straps (#15) as shown in FIG. 12. FIG.
- Page 16 English HOW TO FOLD THE GAME FOR STORAGE STEP 1 STEP 2 WARNING Two Adults Required Fold parts (#8) as shown. Note: Release the tubes by pressing the push button (#P4) as shown. WARNING STEP 3 STEP 4 Do NOT trap your fingers when folding the game.
-
Page 17: Battery Installation
English ELECTRONIC SCOREBOARD INSTRUCTIONS BATTERY INSTALLATION Battery Box: Unscrew the bolt using a screwdriver and open the Battery Box, insert 3 pcs “AAA” batteries (not included) in the order of polarity as shown inside the Battery Box. And then screw on the cover by using a screwdriver. REMINDING: Batteries must be installed according to the correct polarization (+ and -) required. - Page 18 English GAME OPTIONS G1. SINGLE PLAYER, ONE HOOP • Player must score only on the Home hoop. • 2 points are counted for every shot made on the Home hoop only. • Unlimited time , Maximum score: 100 G2.SINGLE PLAYER, ANY HOOP Player must score on HOME or VISITOR hoop.
- Page 19 English DISCLAIMER WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 20 www.vminnovations.com...
