Dimensional drawings

1
2
Legende: DE819513
Technischen Änderungen vorbehalten.
Alle Maße in mm.
A Vorderansicht
C Draufsicht
Keys: UK81513
All dimensions in mm.
Pos. Name
A Front view
C Plan view
1 Return from heating
2 Return to heat pump
Net weight
Nominal volume
8
2
A
445 445
Subject to change without notice | 83030000aUK – Translation of the original operating manual | ait-deutschland GmbH
3

WPSK 40Split

C
Dimension
–
–
R 1"
R 1"
16 kg
39 litres
