- Page 1 Accessories for heat pumps Operating Manual Hydraulic Station 83059300gUK...
-
Page 2: Table Of Contents
....13 Insulate hydraulic connections ....14 10 Set the overflow valve ........ 14 11 Commissioning ..........14 12 Faults .............. 14 12.1 Unlock the safety temperature limiter ..14 Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 3: About This Operating Manual
Heat pump manual order. Additional information, e.g. a tip on making work easier, information on standards Reference to further information elsewhere in the operating manual or in another document ● Listing Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 4: Contact
► Restore earthing connections to their original con- Children must not play with the product. dition after completion of the work. The product may only be opened by qualified personnel. Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 5: Avoid Damage To Property
When the system is filled with untreated drinking wa- ter, calcium precipitates as scale. Lime scale deposits form on the heat transfer surfaces of the heating. The efficiency drops and energy costs rise. In extreme cas- es, the heat exchangers will be damaged. Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 6: Scope Of Supply
12 Expansion tank 13 Buffer tank ● Room control panel for controlling the main func- 14 Draining off buffer tank tions from the living room 15 Feet for adjusting screws ● Electrical connection kit Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 7: Transport, Installation And Assembly
It is recommended that the wooden pallet is on- ly removed after carrying is complete. ► Carry the hydraulic station to the installation site with 3 – 4 people. Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 8: Installation
Place the device on a stable and horizontal sur- ing so, ensure that the connection pipework be- face, preferably decoupled from structure-borne tween the heat pump and hydraulic station are also noise. taken into account. Tilt the device slowly and carefully to one side. -
Page 9: Safety Module
Cable extension details see heat pump manual vessel must be adjusted to the system (ap- prox. 0.5 bar less than the system filling pres- sure) in accordance with calculation accord- ing to the relevant standards (EN 12828). Subject to change without notice | 83059300gUK | ait-deutschland GmbH... - Page 10 Strip the sheathing of all cables to the external loads before laying in the cable gland of the con- trol box. Feed the cable on the rear of the hydraulic station through the cable gland into the switch box. 1 Contactor...
-
Page 11: Installing The Control Device
The values in brackets are for the 6 kW heat- ing element. Disconnected cables must be furnished with screw terminals. Only the phases cited above may be disconnected (safety temperature limiter). Four cut-outs in the switchgear compartment panel Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 12: Flushing, Filling And Venting
As a result, connection it is not necessary to remove the valve motor. 2 Network cable connection 3 LIN-bus cable connection to the controller board 4 Modbus cable to Modbus distributor connection Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 13: Flushing, Filling And Venting The Domestic Hot Water Tank
B of the connections of the 3-way switching valve. Flush heating circuit thoroughly, until no more air is discharged. Position the valve motor (①) on the 3-way switch- ing valve (③). Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 14: Insulate Hydraulic Connections
1 Reset knob 2 safety temperature limiter 3 Electric heating element ► If the safety temperature limiter trips again, con- tact the local partner of the manufacturer or the factory's customer service. Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 15: Dismantling And Disposal
Buffer (standby) battery Use a screwdriver to push out the buffer battery on the processor circuit board of the control ele- ment. Dispose of the buffer battery in accordance with local regulations. Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 16: Technical Data / Scope Of Supply
• yes – no • | • | – • | • | – *) compressor only, **) note local regulations 813320a 813321a Subject to change without notice | 83059300gUK | ait-deutschland GmbH... - Page 17 Controller | Heat quantity recording | Extension board included in scope of supply or integrated: • yes – no • | • | – *) compressor only, **) note local regulations 813326 Subject to change without notice | 83059300gUK | ait-deutschland GmbH...
-
Page 18: Hsdv
• yes – no • | • | – • | • | – *) compressor only, **) note local regulations 813324a 813325a Subject to change without notice | 83059300gUK | ait-deutschland GmbH... - Page 19 Controller | Heat quantity recording | Extension board included in scope of supply or integrated: • yes – no • | • | – *) compressor only, **) note local regulations 813327a Subject to change without notice | 83059300gUK | ait-deutschland GmbH...
-
Page 20: Free Pressing
Volumetric flow of hot water ∆pmax ∆pmax Maximum free pressing Maximum free pressing Legende: Legende: “” Volumenstrom Heizwasser in m “” Volumenstrom Heizwasser in m ∆pmax maximale freie Pressung ∆pmax maximale freie Pressung Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 21: Dimensioned Drawings
R 1ʺ external thread R 1ʺ external thread Circulation pump Circulation pump R 3/ 4 ʺ external thread R 3/ 4 ʺ external thread 10 10 Cold water Cold water R 1ʺ external thread R 1ʺ external thread 11 11 Penetrations for electric/sensor cables Penetrations for electric/sensor cables Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 22: Hs(D)V 12M3
R 1ʺ external thread R 1ʺ external thread Circulation pump Circulation pump R 3/ 4 ʺ external thread R 3/ 4 ʺ external thread 10 10 Cold water Cold water R 1ʺ external thread R 1ʺ external thread 11 11 Penetrations for electric/sensor cables Penetrations for electric/sensor cables Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 23: Hs(D)V 12.1M3
R 1ʺ external thread R 1ʺ external thread 11 11 Penetrations for electric/sensor cables Penetrations for electric/sensor cables 12 12 Adjusting foot M12 (3x) variable height, additional 15-30mm Adjusting foot M12 (3x) variable height, additional 15-30mm Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 24: Installation Plans
All dimensions in mm. Alle Maße in mm. Pos. Pos. Name Name OKF Oberkante Fertigfussboden Freiraum für Servicezwecke FS FS Free space for service purposes Free space for service purposes OKF Top edge of finished floor Top edge of finished floor Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 25: Hs(D)V 12M3, Hs(D)V 12.1M3
All dimensions in mm. OKF Oberkante Fertigfußboden Pos. Pos. Name Name Freiraum für Servicezwecke FS FS Free space for service purposes Free space for service purposes OKF Top edge of finished floor Top edge of finished floor Technische Änderungen vorbehalten. Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 26: Terminal Diagrams
TRL ext. GND5 NTC6 GND6 NTC7 GND7 NTC8 GND8 NTC9 GND9 AGP1 AIN1 AGP2 AIN2 AGND1 AOUT1 AGND2 AOUT2 -X10 -X11 white blue green white / blue brown brown yellow yellow Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 27: Hsdv
TRL ext. GND5 NTC6 GND6 NTC7 GND7 NTC8 GND8 NTC9 GND9 AGP1 AIN1 AGP2 AIN2 AGND1 AOUT1 AGND2 AOUT2 blue -X10 -X11 white / blue brown yellow brown green white Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 28: Terminal Diagram, Mains Connection
Terminal diagram, mains connection heat pump 1~230V HS(D)V 9M1/3 + electric heating element 3~400V HS(D)V 12M3, HS(D)V 12.1M3 3~N/PE/400V/50Hz 1~N/PE/230V/50Hz 1~N/PE/230V/50Hz Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 29: Electric Heating Element 1~230V
HS(D)V 9M1/3 Terminal diagram, mains connection heat pump 1~230V + electric heating element 1~230V 1~N/PE/230V/50Hz 1~N/PE/230V/50Hz 1~N/PE/230V/50Hz Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 30: Terminal Diagram, Mains Connection
Terminal diagram, mains connection heat pump 3~400V HS(D)V 12M3 + electric heating element 3~400V HS(D)V 12.1M3 3~N/PE/400V/50Hz 3~N/PE/400V/50Hz 1~N/PE/230V/50Hz Subject to change without notice | 83059300gUK | ait-deutschland GmbH... -
Page 31: Circuit Diagrams
Circuit diagram 1/2 white blue green white / blue brown brown yellow yellow Subject to change without notice | 83059300gUK | ait-deutschland GmbH... - Page 32 Circuit diagram 2/2 OUT1 Out7 AIN1 AOUT1 NTC3 GND3 NTC6 GND6 NTC8 GND8 NTC9 GND9 Subject to change without notice | 83059300gUK | ait-deutschland GmbH...
-
Page 33: Hsdv
HSDV Circuit diagram 1/2 blue white / blue brown yellow brown green white Subject to change without notice | 83059300gUK | ait-deutschland GmbH... - Page 34 Circuit diagram 2/2 HSDV OUT1 Out7 yellow white AIN1 X2.3 X1.3 green AGND1 X2.2 X1.2 /1.C6 brown AOUT1 X2.1 X1.1 /1.C6 NTC3 GND3 NTC6 GND6 NTC8 GND8 NTC9 GND9 Subject to change without notice | 83059300gUK | ait-deutschland GmbH...
- Page 35 Subject to change without notice | 83059300gUK | ait-deutschland GmbH...
- Page 36 GmbH Industriestraße 3 D-95359 Kasendorf www.ait-deutschland.eu...
