Operating Manual
Hydraulic module
UK
83059200dUK – Translation of the original operating manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDV 9-1/3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AIT HDV 9-1/3

  • Page 1 Accessory for heat pumps Operating Manual Hydraulic module 83059200dUK – Translation of the original operating manual...
  • Page 2: Table Of Contents

    ..........15 12 Faults ..............15 12.1 Unlock safety temperature limiter ....15 13 Dismantling and disposal ......16 13.1 Dismantling ...........16 13.2 Disposal and recycling ........16 Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 3: About This Operating Manual

    Additional information, e.g. a tip on making work easier, information on standards Reference to further information  elsewhere in the operating manual or in another document ● Listing Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 4: Contact

    Faults and the failure of components, e.g. pumps, valves ● Internal and external leaks, e.g. from heat exchangers ● Cross-section reduction blockages components, e.g. heat exchanger, pipes, pumps Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 5: Operation And Maintenance

    Wipe down the outside of the unit only using a damp cloth or cloth with mild cleaning product (washing-up liquid, neutral cleaning agent). Never use any harsh, abrasive, acid or chlorine-based cleaning products Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 6: Scope Of Supply

    Inspect the delivery for outwardly visible signs of damage. Inspect the scope of supply for completeness. Any defects or incorrect deliveries must be reported immediately. Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 7: Components Of The Unit

    Electric heating element Air separator Heating circuit safety module (insulated) 10 Control panel for regulating 11 Electrical switch box 12 Supply inlet 13 Draining Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 8: Transport, Installation And Assembly

    Secure the hydraulic module to the handcart with hole template. lashing straps. Take off the front hood. Use the plugs and screws supplied to fix the hydraulic module onto the wall: Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 9: Installation / Hydraulic Connection To Heating Circuit

    (EN 12828). NOTE Before connection to the heating system, the heating circuit must be thoroughly flushed. „Dimensioned drawings and drill patterns“, from  page 20 Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 10: Electrical Installation

    1 Connection, bus cable EVS/EVS8 2 Connection, load cable EVS/EVS8 3 Cable glands 4 Contactor 5 Control panel 6 Cable routing 7 Return flow sensor Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 11 4 Control voltage (for dual heat pump only) 5 Hydraulic module 6 Heating element load line 7 Control voltage 8 Load Compressor 9 Sub-distribution Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 12: Installing The Control Panel

    There are 4 hooks at the rear of the control panel, which are used to hook the control panel onto the switchgear compartment panel: Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 13: Flushing, Filling And Venting The System

    Pull the valve motor carefully off the 3-way valve (3). switching valve (3). Insert the U-clip (2) into the base of the valve motor. Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 14 2 Return, hot water 3 Supply, hot water / domestic hot water 4 Filling stop cock 5 Heat pump 6 Drain  “Switching valve” operating manual Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 15: Insulate Hydraulic Connections

    ► Press the reset button back in again. 1 Safety temperature limiter on the electric heating element 2 Reset button 3 Electric heating element Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 16: Dismantling And Disposal

    Use a screwdriver to push out the buffer battery on the processor board of the control panel. Dispose of the buffer battery in accordance with local regulations. Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 17: Technical Data / Scope Of Supply

    • yes – no • | • | – • | • | – *) compressor only, **) note local regulations 813318a 813319a Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 18: Hdv

    • yes – no • | • | – • | • | – *) compressor only, **) note local regulations 813322a 813323a Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 19: Free Pressing

    ∆pmax Maximum free pressing 823287 823283 Legende: Legende: “” “” Volumenstrom Heizwasser in m Volumenstrom Heizwasser in m ∆pmax maximale freie Pressung ∆pmax maximale freie Pressung Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 20: Dimensioned Drawings And Drill Patterns

    All dimensions in mm. Spacing for drill pattern. Pos. Name Drill hole Ø12 for plug (incl. accessory package) Legende 819403a Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH Abstände für Bohrbild...
  • Page 21: H(D)V 12-3

    Technische Änderungen vorbehalten. Keys: UK819493 All dimensions in mm. Spacing for drill pattern. Pos. Name Drill hole Ø12 for plug (incl. accessory package)) Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 22: Installation Plans

    Zust. Änderungstext Datum Ers. f. Keys: UK819398 / 819488 All dimensions in mm. Pos. Bezeichnung Free space for service purposes OKF Top edge of finished floor Free space for wall-hanging buffer tank possible Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 23: Terminal Diagrams

    GND8 NTC9 GND9 AGP1 AIN1 AGP2 AIN2 AGND1 AOUT1 AGND2 AOUT2 -X10 -X11 white blue green white / blue brown brown yellow yellow Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 24: Hdv

    NTC8 GND8 NTC9 GND9 AGP1 AIN1 AGP2 AIN2 AGND1 AOUT1 AGND2 AOUT2 blue -X10 -X11 white / blue brown yellow brown green white Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 25: Terminal Diagram, Mains Connection

    Terminal diagram, mains connection heat pump 1~230V H(D)V 9-1/3 + electric heating element 3~400V HDV 12-1/3 3~N/PE/400V/50Hz 1~N/PE/230V/50Hz 1~N/PE/230V/50Hz Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 26: Electric Heating Element 1~230V

    H(D)V 9-1/3 Terminal diagram, mains connection heat pump 1~230V + electric heating element 1~230V 1~N/PE/230V/50Hz 1~N/PE/230V/50Hz 1~N/PE/230V/50Hz Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 27: Electric Heating Element 3~400V

    Terminal diagram, mains connection heat pump 3~400V HV 12-3 + electric heating element 3~400V 3~N/PE/400V/50Hz 3~N/PE/400V/50Hz 1~N/PE/230V/50Hz Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 28 Circuit diagram 1/2 blue white white / blue green brown brown yellow yellow Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 29: Circuit Diagrams

    Circuit diagram 2/2 OUT1 Out7 AIN1 AOUT1 NTC6 GND6 NTC8 GND8 NTC9 GND9 Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 30: Hdv

    Circuit diagram 1/2 blue white / blue brown yellow brown green white Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
  • Page 31 Circuit diagram 2/2 OUT1 Out7 yellow white AIN1 green AGND1 brown AOUT1 NTC6 GND6 NTC8 GND8 NTC9 GND9 Subject to change without notice | 83059200dUK – Translation of the original operating manual | ait-deutschland GmbH...
