PotteryBarn HOTEL DOUBLE DOOR CABINET Assembly Instructions

Note:
•
This hanging system is meant for drywall/stud mounting only.
•
If walls are concrete, brick or plaster, please consult your local hardware store for assistance.
•
Professional Installation Recommended – Otherwise, for safety and ease of mounting, installation by two
people is recommended.
•
The maximum individual shelf weight capacity is 20 pounds and the total product weight capacity of
100 pounds.

Hardware Included:

•
(2) Shelves
•
(8) Shelf Brackets
•
(1) 18" Wall Bracket
•
(2) Toggle Screws
•
(2) Toggles
(Toggles/Screws are meant for drywall only)
•
(1) Wood Screw
•
(1) Small Anchor
•
(1) Small Screw
•
(1) Plastic Plug
•
Metal Knob and Screw

Pre-Assembly:

•
Remove all parts and hardware from the box and lay out on a clear workspace, along with any plastic
protective packaging. Do not dispose of any contents until assembly is complete to avoid accidentally
discarding small parts or hardware.
•
Use the parts and hardware lists above to identify and separate each of the pieces included.
•
The illustrations provided allow for easier assembly when used in conjunction with the assembly instructions.

INSTALLATION SUMMARY:

FIND WALL STUDS

MOUNT WALL BRACKET TO THE WALL

Hang The Product Onto The Mounted Wall Bracket
FIND WALL STUDS:
1. Determine the desired placement on the wall for the product. Within that range, locate a stud using a stud
finder and make a small mark on the wall with a pencil at that location.
2. It is best to mount the bracket to at least (1) stud. Using Figure 1, determine which hole on the wall bracket
will be over the stud, this hole will take a wood screw alone.
Note: it is possible the bracket may align over two wall studs.
MOUNT WALL BRACKET TO THE WALL
1. Insert the supplied bubble level into the channel of the wall bracket. Position the wall bracket on the wall
and adjust so that the bracket is level and a pre-drilled hole of the bracket aligns with a stud. Then, use a
felt-tipped pen to mark the wall through appropriate pre-drilled holes of the bracket to indicate the locations
of the drywall toggles. Also make sure to mark the bracket itself at each selected pre-drilled hole using the
pen. (Please refer to Figure 1 to determine the location of the hardware.) The locations of the drywall
toggles will depend on how the stud aligns with the bracket. The user should make sure that the stud and
the toggles are evenly spaced along the length of the bracket and that the ends of the bracket should be
secured using either a stud-mounted screw or a drywall toggle.
2. Remove the wall mount bracket and set aside.
3. Using a manual screwdriver, drive a toggle into the drywall at each mark. To install these toggles into the
wall, simply rotate them at the marked location as if they were a large screw, applying smooth even force.
DO NOT HIT THEM WITH A HAMMER AND DO NOT USE A POWER DRILL TO ROTATE THEM. These
toggles are designed to bore themselves into the wall. Continue rotating until the toggle head advances
flush with the wall surface.
HOTEL DOUBLE DOOR CABINET WITH CUBBIES
Assembly Instructions

Tools Needed:

•
Stud Finder
•
#2 Phillips Screwdriver
•
Pencil
