Summary of Contents for PotteryBarn CLARA FULL BED
- Page 1 CLARA FULL BED ASSEMBLY INSTRUCTIONS Date: 2014-Oct.-16 www.potterybarn.com Rev: Page 1/ 6...
- Page 2 Important Safety Instructions: Please read all instructions carefully before assembling. For your safety, assembly by two or more adults is strongly recommended. Keep these instructions for future use. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 3 Assembly Instruction Steps: Note: The mattress support on the side rails is pre-assembled in the low position when shipped to allow bed to be used with a box spring mattress. If you intend to use your bed without a box spring, the extra mattress support rail...
- Page 4 5. Roll out the 2 Slat Roll (D) onto the slat support rail of the Side Rails (C) as seen in the illustration below. 6. Secure the slat rolls with 64 Wood Screws (I) using a Phillips Head Screwdriver (not included). Assembly Instructions (High position): 7.
- Page 5 8. Roll out the Slat Roll (D) onto the slat support rail of the Side Rails (C) and secure the slat rolls with Wood Screw (I) using a Phillips Head Screwdriver. If the Bed doesn’t sit level, adjust the levelers underneath the legs in or out. Assembly is complete.
- Page 6 We do not recommend the use of chemical cleansers, abrasives, or furniture polish on our lacquered finish. Hardware may loosen over time. Periodically check to make sure all connections are tight. Re-tighten if necessary. Thank you for your purchase Stores | catalog | www.potterybarn.com Page 6/ 6...
- Page 7 CLARA QUEEN AND KING BED ASSEMBLY INSTRUCTIONS Date: 2014-Oct.-23 www.potterybarn.com Rev: 2014-Dec-12 Page 1/ 10...
- Page 8 Important Safety Instructions: Please read all instructions carefully before assembling this Bed. For your safety, assembly by two or more adults is strongly recommended. Keep these instructions for future use. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 9 Hardware Enclosed: H- Flat Washer – 12x I- Spring Washer – 12x J- Short Allen Bolt – 12x K- Long Allen Bolt – 1x M6x25 mm M6x150 mm L- Allen Key – 1x M- Wood Screw – 64x 4x30 mm Tools Required (not included): Philips Head Screwdriver Assembly Instruction Steps:...
- Page 10 4. Repeat steps #1 - #3 to attach the Footboard (B) to the 2 Side Rails (C), as seen in the illustration below. 5. Attach the 3 Short Support Legs (F) to the Center Support Rail (D), by inserting the hanger bolts into the insert nut found at the Center Support Rail, as seen in the illustration below.
- Page 11 9. Attach the assembled Center Support Rail (D) to the Headboard and Footboard (A&B), by inserting the metal bracket at the two ends of the Center Support Rail (D) into the corresponding hook on the Headboard and Footboard (A&B). Slightly press down to secure. Note: Turn in/out the leveler found at the bottom of Support Legs if needed, so they can touch the floor and can support the Center Support Rail.
- Page 12 11. Secure the slat rolls with 64 Wood Screws (M) using a Phillips Head Screwdriver (not included). 12. If the bed does not sit level, adjust the levelers found underneath the legs. Page 6/ 10...
- Page 13 Assembly Instructions (High position): 13. The bed is assembled in the low position when shipped. If you wish to use it without a box spring, follow the instructions below: a. Move the adjustable mattress support rail found below the fix rail at the Side Rail (C) to the higher location, by removing the Allen Bolts and Washers that were pre-installed.
- Page 14 14. Move the brackets found at the Headboard (A) and Footboard (B) to the higher location, by first removing the screws (with a Philips Head Screwdriver) and then re-position the holes to the higher location, as seen in the illustration below. 15.
- Page 15 16. Secure/store the Short Support Legs (F) to the Center Support Rail (D) and secure with a Long Allen Bolt (K), as seen in the illustration below. 17. Use the Allen Key (L) to tighten the Long Allen Bolt (K), as seen below. 18.
- Page 16 We do not recommend the use of chemical cleansers, abrasives, or furniture polish on our lacquered finish. Hardware may loosen over time. Periodically check to make sure all connections are tight. Re-tighten if necessary. Thank you for your purchase Stores | catalog | www.potterybarn.com Page 10/ 10...
