  • Page 1: Quick Start Guide

    Prestige 2302R Series VoIP Station Gateway Quick Start Guide Version 3.60 1/2005...
  • Page 2 Overview This Quick Start Guide covers the Prestige (P2302R) and (P2302RL) models. It explains how to use your Prestige to make phone calls through the Internet. See your User’s Guide for more information on all features. The Prestige 2302RL’s lifeline feature adds regular phone services (that do not use the Internet). The following figure shows your Prestige (A) connected to the modem or router that provides your Internet connection (B).

  • Page 3: Hardware Connections

    2 Hardware Connections 1 LAN: Connect a computer or an Ethernet switch to this port with an Ethernet cable. 2 WAN: Connect a broadband modem or router to this port with an Ethernet cable. 3 LINE: (Prestige 2302RL only). Use telephone wire to connect this port to the telephone jack. This is a FXO (Foreign Exchange Office) port.

  • Page 4: Initial Configuration

    3 Initial Configuration In this section you will access your Prestige and configure it for Internet access and making phone calls through the Internet. Instructions are also provided for configuring the P2302RL to make regular calls. 1 Launch your web browser. Enter “192.168.1.1” as the web site address. 2 Click Login.

  • Page 5: Internet Access Setup

    3.1 General Setup (Optional) This screen is optional. You can just click Next. System Name is for identifying the Prestige. You can enter your computer's "Computer Name". Domain Name: Manually enter a domain name if you want to. You can also leave it blank or set to whatever may have displayed automatically.
  • Page 6 Prestige 2302R Series If you are not using Ethernet encapsulation and are given a username and password, you are using either PPP over Ethernet or PPTP encapsulation. Enter the information provided. Select Nailed-Up Connection when you want your connection up all the time (this could be expensive if your ISP bills you for Internet usage time instead of a flat monthly fee).
  • Page 7 Prestige 2302R Series 3.2.4 PPTP Enter the following if you are using PPTP. User Name Password My IP Address/Subnet Mask Server IP Address Connection ID/Name (if provided) You can leave the other fields set to the defaults.
  • Page 8 3.3 WAN IP Address and DNS Server Settings If you were given IP address and/or DNS server settings, enter them in the fields. Otherwise leave the default settings and just click Next. 3.4 SIP Account 1 Setup Note: You should have a voice account already set up. Fill in the fields with information from your voice service provider.
  • Page 9 Prestige 2302R Series If you have a SIP account like 1234@VoIP- provider.com,“1234” would be the SIP Number and “VoIP-provider.com” would be the SIP Service Domain. REGISTER Server Address/Port: If you have no registrar server information, copy what you entered in the SIP Server Address/Port fields.

  • Page 10: Speed Dial Configuration

    Prestige 2302R Series 3.5 Speed Dial Configuration Click PHONE BOOK in the navigation panel and then Speed Dial. Speed dial provides shortcuts for dialing frequently used (VoIP) phone numbers. You can use speed dial entries for peer-to- peer calls or SIP numbers that use letters. Select a speed dial key combination.

  • Page 11: Lifeline Configuration

    3.6 Lifeline Configuration (P2302RL) Click PHONE BOOK in the navigation panel and then Lifeline. PSTN Pre-fix Number: If you want to make a regular call when the PWR/VoIP LED is orange, dial the prefix number that you configure here and the phone number. If the PWR/VoIP LED is green or off, make regular calls without a prefix number.

  • Page 12: Troubleshooting

    5 Troubleshooting PROBLEM CORRECTIVE ACTION None of the LEDs turn Make sure that you have the correct power adaptor connected to the Prestige and an on when you connect appropriate power source. Make sure that the power source is turned on. Check all cable the Prestige’s power.

  • Page 13: Safety Warnings

    5 The Internet Protocol TCP/IP Properties screen opens (the General tab in Windows XP). 6 Select the Obtain an IP address automatically and Obtain DNS server address automatically options. 7 Click OK to close the Internet Protocol (TCP/IP) Properties window. 8 Click Close (OK in Windows 2000/NT) to close the Local Area Connection Properties window.
  • Page 14 Prestige 2302R Series • If you wall mount your device, make sure that no electrical, gas or water pipes will be damaged. • Do NOT install nor use your device during a thunderstorm. There may be a remote risk of electric shock from lightning.
