P-2301/2R-P1C
VoIP ATA / Station Gateway
P-2301RL-P1C
VoIP ATA / Station Gateway with Lifeline
User's Guide
Version 3.60
3/2007
Edition 1
Copyright © 2007. All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2R-P1C and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications 2R-P1C

Summary of Contents for ZyXEL Communications 2R-P1C

  • Page 1 VoIP ATA / Station Gateway P-2301RL-P1C VoIP ATA / Station Gateway with Lifeline User’s Guide Version 3.60 3/2007 Edition 1 Copyright © 2007. All rights reserved...

  • Page 2: Table Of Contents

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 1 Overview This guide helps you set up and use your ZyXEL P-2301R- P1C, P-2301RL-P1C or P-2302R-P1C (the “ZyXEL Device”). This guide contains the following sections: Section Installation Requirements Making Hardware Connections Initial Configuration Making Phone...
  • Page 3 P-2301/2R-P1C / P-2301RL-P1C User’s Guide The following figure shows a typical way to use your ZyXEL Device. • When you make a phone call over the Internet, you use a telephone (A) to dial the number. The P-2301R-P1C and P- 2301RL-P1C support one telephone connection, and the P- 2302R-P1C supports two telephone connections.

  • Page 4: Installation Requirements

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide • P-2301RL-P1C only: use your telephone (A) to make calls over the regular telephone network (PSTN or Public Switched Telephone Network). The following table contains useful information about your ZyXEL Device. Default management IP Address...

  • Page 5: Making Hardware

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 3 Making Hardware Connections 1 LINE (P-2301RL-P1C only): Use a telephone cable to connect the telephone jack to this port.

  • Page 6: Initial Configuration

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 2 PHONE / PHONE 1: Use a telephone cable (and any telephone adaptor provided with your ZyXEL Device) to connect your telephone to this port. 3 PHONE 2 (P-2302R-P1C only): connect another telephone to this port. If you have only one phone, use the PHONE 1 port.
  • Page 7 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 2 Enter http://192.168.1.1 3 Click Login. 4 Type a new password, re-type it to confirm, and click Apply. The next time you log in, you should not see this screen. as the address.
  • Page 8 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 5 Click Go to Advanced setup. 6 The Status screen appears. Click the Wizard icon ( the upper right corner. If the INTERNET light is green, go to section 16. Otherwise, go to section 4.34.3 4.24.2...

  • Page 9: Connection Wizard

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 4.2 Connection Wizard If you subscribe to a Roadrunner service, you cannot use the Connection Wizard case, please use the Network > WAN > Internet Connection screen to enter your information. You must have an Internet account set up and ready to use to complete this section.
  • Page 10 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 2 Click Next. 3 System Name is used to identify the ZyXEL Device on the network. Use the default value, unless you know the name is already used in the network. Domain Name (optional): Enter the appropriate name, if there is one, or use the default value.
  • Page 11 P-2301/2R-P1C / P-2301RL-P1C User’s Guide • If your ISP gave you a user name and password, select PPP over Ethernet. • If your ISP did not give you a username and password, select Ethernet. Then, follow the instructions in the appropriate section below.
  • Page 12 P-2301/2R-P1C / P-2301RL-P1C User’s Guide Select Use fixed IP address provided by your ISP if your ISP gave you a static IP address. Then, click Next. 3 Enter the information provided by your ISP. If your ISP did not provide information for any of the fields in this screen,...
  • Page 13 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 4 Select Factory default, unless you need to spoof your computer’s MAC address. Then, click Apply. 5 Click Finish. 6 Launch another web browser, and go to any web site (for example, http://www.zyxel.com). If you cannot access the...
  • Page 14 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 1 Enter the information provided by your ISP. If your ISP did not provide information for any of the fields in this screen, leave them at their default settings. Then, click Next. 2 Select Get automatically from your ISP if your ISP did not give you an IP address.
  • Page 15 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 3 Enter the information provided by your ISP. If your ISP did not provide information for any of the fields in this screen, leave them at their default settings. Then, click Next. 4 Select Factory default, unless you need to spoof your...

  • Page 16: Voip Setup Wizard

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 5 Click Finish. 6 Launch another web browser, and go to any web site (for example, http://www.zyxel.com). If you cannot access the Internet, see Troubleshooting 4.3 VoIP Setup Wizard You must have Internet access and a VoIP account before you can complete this section.
  • Page 17 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 1 In the Wizard Setup screen, click VoIP Setup. 2 Enter the information provided by your VoIP service provider. If you have a VoIP account like “1234@VoIP- provider.com”, the SIP Number is “1234”, and the SIP Service Domain is “VoIP-provider.com”.
  • Page 18 P-2301/2R-P1C / P-2301RL-P1C User’s Guide Click Apply. 3 Wait while the ZyXEL Device tries to register the VoIP account(s). 4 Click Finish. The PHONE light should be green. P-2302R-P1C Only...

  • Page 19: Bandwidth Management Wizard

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 4.4 Bandwidth Management Wizard This Bandwidth Management Wizard allows you to specify the amount of bandwidth you allow certain applications to use on the ZyXEL Device. Use this wizard only if you want to ensure that certain applications, such as you VoIP calls, get enough bandwidth.
  • Page 20 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 1 Click Next. In the screen that appears, select the Active checkbox. Enter the total amount of traffic the device can send to the WAN in the Managed Bandwidth (kbps) field. This does not affect the total amount of traffic the device can send to the LAN.
  • Page 21 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 2 In the next screen, select the services you want to have higher priority. The following table describes the services available in this screen. Service Description XBox Live This is Microsoft’s online gaming service that lets you play multiplayer XBox games over the Internet via broadband technology.
  • Page 22 P-2301/2R-P1C / P-2301RL-P1C User’s Guide You should select at least one service. If you do not select a service, or do not see its name in this screen, it receives a lower priority. Click Next. 3 Set the priority of each service. If a service has higher priority than other services, then it can use as much remaining bandwidth as it needs.
  • Page 23 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 4 Click Finish. 4.5 PSTN Phone Line Configuration (P- 2301RL-P1 only) When one of your VoIP accounts is registered, the ZyXEL Device normally uses the Internet (VoIP) rather than the regular PSTN phone line to make phone calls. Use this section to set certain phone numbers (emergency services, for example) to always use the regular (PSTN) line.

  • Page 24: Bridge Mode

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide In the main screen, click VoIP > PSTN Line. PSTN Line Pre-fix Number: Enter a number of 1 ~ 4 digits. When you enter this number on your telephone keypad, the ZyXEL Device uses the PSTN line to call the number you dial next.
  • Page 25 P-2301/2R-P1C / P-2301RL-P1C User’s Guide • There is another router or gateway in the network, • You only want to use the ZyXEL Device for VoIP and Internet access. You do not want to use other features, such as the firewall, even with their default settings.

  • Page 26: Making Phone Calls

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide The ZyXEL Device automatically restarts. When the POWER light stops blinking and stays on, follow the directions in section on page However, use the Management IP Address you set up in step 3, instead of http://192.168.1.1. If your computer’s IP address is in a different subnet, follow the directions in Computer’s IP Address...

  • Page 27: Troubleshooting

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide For the P-2301RL-P1, follow these directions to make phone calls that do not use the Internet. • If the PHONE light is off (indicating that you do not have a VoIP account registered) just dial the phone number.

  • Page 28: The Login Screen

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide Make sure the power source is turned on. If the problem continues, contact your vendor. The POWER light is red. Unplug the device, and plug it in again. If the problem continues, contact your vendor.
  • Page 29 P-2301/2R-P1C / P-2301RL-P1C User’s Guide Make sure your computer’s Ethernet adapter is installed and functioning properly. If you changed the ZyXEL Device’s mode or IP address, make sure you use the new IP address in the Address or URL field in the web browser.
  • Page 30 P-2301/2R-P1C / P-2301RL-P1C User’s Guide When I pick up the phone’s receiver, I hear no dial tone. Check the connection between your telephone and the ZyXEL Device. See section 3. Test the telephone wire. 1 Connect the wire to a telephone and a regular telephone outlet.

  • Page 31: Resetting The Zyxel Device

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 6.1 Resetting the ZyXEL Device This changes all the ZyXEL Device’s settings to their original values. You have to make all of your changes again. See section on page for information on default settings. Make a note of your settings before you reset the ZyXEL Device.
  • Page 32 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 2 In Windows XP, click Network Connections. In Windows 2000/NT, click Network and Dial-up Connections. 3 Right-click on your network connection (for example, Local Area Connection). A menu appears, like the one shown here. 4 In the menu, click Properties. The network connection’s properties screen appears.
  • Page 33 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 6 Click Properties underneath the list. The Internet Protocol (TCP/IP) Properties screen appears. 7 Select Obtain an IP address automatically. 8 Select Obtain DNS server address automatically. 9 Click OK. 10Close the other windows. 6.2.2 Windows 95/98/Me...
  • Page 34 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 1 Click Start > Settings > Control Panel and double-click the Network icon to open the Network window. The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/ IP protocol and Client for Microsoft Networks.
  • Page 35 P-2301/2R-P1C / P-2301RL-P1C User’s Guide • Select TCP/IP from the list of network protocols and then click OK. If you need Client for Microsoft Networks: • Click Add. • Select Client and then click Add. • Select Microsoft from the list of manufacturers.
  • Page 36 P-2301/2R-P1C / P-2301RL-P1C User’s Guide • If you have a static IP address, select Specify an IP address and type your information into the IP Address and Subnet Mask fields. 5 Click the DNS Configuration tab. • If you do not know your DNS information, select Dis-...

  • Page 37: Macintosh Os X

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide • If you know your DNS information, select Enable DNS and type the information in the fields below (you may not need to fill them all in). 6 Click the Gateway tab. • If you do not know your gateway’s IP address, remove previously installed gateways.
  • Page 38 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 1 Click the Apple menu, and click System Preferences to open the System Preferences window. 2 Click Network in the icon bar. • Select Automatic from the Location list. • Select Built-in Ethernet from the Show list.
  • Page 39 P-2301/2R-P1C / P-2301RL-P1C User’s Guide 3 For dynamically assigned settings, select Using DHCP from the Configure list. 4 For static settings, do the following: • From the Configure box, select Manually. • Type your IP address in the IP Address box.

  • Page 40: Wall Mounting

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 7 Wall Mounting Instructions Do the following to hang your ZyXEL Device on a wall. 1 Select a position free of obstructions on a sturdy wall. 2 Drill two holes for the screws. Make sure the distance...

  • Page 41: Specifications

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 5 Align the holes on the back of the ZyXEL Device with the screws on the wall. Hang the ZyXEL Device on the screws. 8 Specifications Specifications are accurate at the time of writing. Feature...
  • Page 42 P-2301/2R-P1C / P-2301RL-P1C User’s Guide Feature Phone ports Feeding Voltage Ringing Voltage Line Ports (P-2301RL- P1C Only) Operation Temperature Storage Temperature Operation Humidity Storage Humidity Specification P-2301R-P1C and P-2301RL-P1C: One FXS (Foreign eXchange Station) POTS port. P-2302R-P1C: Two FXS (Foreign eXchange Station) POTS ports.

  • Page 43: Features

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 9 Features Voice Functions Protocol Support SIP (RFC 3261) version 2 SDP (RFC 2327) RTP (RFC 1889) RTCP (RFC 1890) G.168 Echo Cancellation VAD (Voice Activity Detection) Silence Suppression CNG (Comfort Noise Generation) QoS Supports ToS and Diffserv Tagging Compression: G.711 (PCM), G.729 (ADPCM)
  • Page 44 P-2301/2R-P1C / P-2301RL-P1C User’s Guide Management Firewall Content Filtering NAT/SUA Static Routes Other Features Embedded Web Configurator CLI (Command Line Interpreter) Remote Management via Telnet or Web FTP/TFTP for firmware downloading, configuration backup and restoration Syslog Built-in Diagnostic Tools for FLASH memory, RAM and LAN port Stateful Packet Inspection.

  • Page 45: Safety Warnings

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 10 Safety Warnings For your safety, be sure to read and follow all warning notices and instructions. • Do NOT use this product near water, for example, in a wet basement or near a swimming pool.

  • Page 46: Related Documentation

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide to order a new one. • Do not use the device outside, and make sure all the connections are indoors. There is a remote risk of electric shock from lightning. • Do NOT obstruct the device ventilation slots, as insufficient airflow may harm your device.

  • Page 47: Legal Information

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 11 Legal Information Certifications Federal Communications Commission (FCC) Interference Statement The device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: • This device may not cause harmful interference.

  • Page 48: Zyxel Limited Warranty

    P-2301/2R-P1C / P-2301RL-P1C User’s Guide 3 Select the certification you wish to view from this page. ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase.
  • Page 49 • Telephone: +886-3-578-3942 • Fax: +886-3-578-2439 • Web Site: www.zyxel.com, www.europe.zyxel.com • FTP Site: ftp.zyxel.com, ftp.europe.zyxel.com • Regular Mail: ZyXEL Communications Corp., 6 Innovation Road II, Science Park, Hsinchu 300, Taiwan Costa Rica • Support E-mail: soporte@zyxel.co.cr • Sales E-mail: sales@zyxel.co.cr •...

  • Page 50: North America

    Centre, 050010, Almaty, Republic of Kazakhstan North America • Support E-mail: support@zyxel.com • Sales E-mail: sales@zyxel.com • Telephone: +1-800-255-4101, +1-714-632-0882 • Fax: +1-714-632-0858 • Web Site: www.us.zyxel.com • FTP Site: ftp.us.zyxel.com • Regular Mail: ZyXEL Communications Inc., 1130 N. Miller St., Anaheim, CA...
  • Page 51 • Support E-mail: support@zyxel.no • Sales E-mail: sales@zyxel.no • Telephone: +47-22-80-61-80 • Fax: +47-22-80-61-81 • Web Site: www.zyxel.no • Regular Mail: ZyXEL Communications A/S, Nils Hansens vei 13, 0667 Oslo, Norway Poland • E-mail: info@pl.zyxel.com • Telephone: +48 (22) 333 8250 •...

  • Page 52: User Guide Feedback

    • Fax: +44-1344 303034 • Web Site: www.zyxel.co.uk • FTP Site: ftp.zyxel.co.uk • Regular Mail: ZyXEL Communications UK, Ltd.,11 The Courtyard, Eastern Road, Bracknell, Berkshire, RG12 2XB, United Kingdom (UK) +” is the (prefix) number you dial to make an international telephone call.
  • Page 53 P-2301/2R-P1C / P-2301RL-P1C User’s Guide Communications, Inc. Other trademarks mentioned in this publication are used for identification purposes only and may be properties of their respective owners.
