B. Change display direction
On the measuring interface, short press the button to change the display.
C. Pause alarm:
a) Alarm including the alarm of measure data's going beyond the limits, the alarm of low-voltage,
the alarm of finger's out of position.
b) On the measuring interface, if the alarm function is on, during the period of alarming, you can
pause it by pressing the button shortly, but the function will be renewed in about 30 seconds.
c) If you want to turn off the alarm for good, you should enter the menu for operation.
D. Data transmission setting
Firstly, please install the affiliated software into the computer, and two icons would appear on the
desktop after installation. The icon of "SpO "is a program for receiving real-time data which is
2
shown as Figure 5; the icon of "SpO Review" is a program for receiving stored data which is shown
2
as Figure 6.
a. Please connect the device to computer with the affiliated data line , then double click the "SpO
2
"icon to start the program.
b. When you unplug the data line from computer, there is a dialog box "Save data at view"
appearing on the desktop, in which you can input some patient's basic information.
Figure 5. SpO program
2
Figure 6. SpO2 Review program
If the users choose to turn on the synchronizing display function on computer, it would
probably take several seconds for the data to appear on the computer screen.
E. Menu operations
On the measuring interface , the display direction can be changed by pressing the power button with
a short push (click). There are six modes of data display that can be viewed.
Press the power button with a prolonged push (1 second) to enter the Settings Menu Interface (see
Figure 7).
The user can setup the following parameters in the Settings Menu –Turn on alarm, turn on pulse
sound, alarm high-low limits, data storage (recording).
Please note in the Settings Menu:
CLICK = short press of power button and PRESS = prolonged push of power button (1sec)
