Electrical supply system details

TN system
rated supply voltage
3x400V
insulation rated voltage
400V
rated impulse withstand voltage
2.5 kV
Rated short-time current Icw for individual circuits - effective
value of the periodic component withstood for 1 s, i.e. short-circuit current
expected at switching voltage
6 kA
rated short-circuit current 6 kA
rated coefficient of diversity 0.8
rated frequency 50 Hz ± 1 Hz
degree of protection IP00
permissible operating temperature 0 x 50 ° C
control circuits supply voltage 24 V DC
VVS180 12 1x18
VVS230 12 1x18
VVS300 12 1x18
VVS400 12 1x18
VVS500 12 1x18
VVS650 12 1x18
NVS23 6 1x18
NVS39 6 1x18
NVS65 6 1x18
NVS80 6 1x18
5
17,3/17,3/17,3
17,3/17,3/17,3
17,3/17,3/17,3
17,3/17,3/17,3
17,3/17,3/17,3
17,3/17,3/17,3
8,7/8,7/8,7
8,7/8,7/8,7
8,7/8,7/8,7
8,7/8,7/8,7
