Technical Specifications
Power supply
10 ... 30VDC
typ. 0.06W, max. 1.1W (when
Power consumption
rain sensor heating is on)
Power loss
max. 1.1W
Interfaces
Loxone Tree:
connection with Miniserver /
Tree Extension
Ambient temperature
-30 ... 70°C / -22 ... 158°F
Wind detection range
9 ... 145km/h / 5.6 ... 90mph
Brightness detection range
0 ... 188000lx
Temperature detection range
-40 ... 125°C / -40 ... 257°F
Rain sensor
with integrated heating
IP44
Safety rating
This device is free of main-
Maintenance & Cleaning
tenance and may only be
cleaned with a dry cloth.
Connection
Wire cross-section
0.08 ... 0.32mm² / AWG28 ... 22
Stripping length
3.5mm / 0.14"
Temperature resistance
-40 ... 125°C / -40 ... 257°F
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Weather
Station
Tree
Part No: 100246
