Technical Specifications
Power Supply
10...30VDC SELV
Power Consumption
typ. 0.06W, max. 1.1W (when
rain-sensor heating is on)
Heating of Rain-Sensor Surface
Yes
Safety Rating
IP44
Ambient Temperature
-30...85°C / -22...185°F
Wind Detection Range
9...145km/h / 5.6...90mph
Brightness Detection Range
0...188kLux
Temperature Detection Range
-40...125°C / -40...257°F
Maintenance & Cleaning
This device is free of main-
tenance and may only be
cleaned with a dry cloth.
Connection
Wire Diameter
0.14...1mm²
AWG18...AWG25
Exposed Wire Length
7mm / 9/32"
Push-In-Technology
To make connection, insert
the wire; to remove the wire
twist and pull at the same
time.
No Gimmicks.
Real Smart Homes.
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Weather
Weather
Station Tree
Station Tree
Station Tree
Part No.: 100246
Part No.: 100246
Advertisement
Related Manuals for LOXONE Weather Station Tree
Summary of Contents for LOXONE Weather Station Tree
- Page 1 9...145km/h / 5.6...90mph Brightness Detection Range 0...188kLux Temperature Detection Range -40...125°C / -40...257°F Maintenance & Cleaning This device is free of main- tenance and may only be cleaned with a dry cloth. Loxone Electronics GmbH Smart Home 1 4154 Kollerschlag Austria loxone.com...
- Page 2 About the product The Weather Station Tree detects important weather conditi- ons for your Smart Home. Together with the Miniserver, you can Push on both side and measure wind, rain, brightness and temperature data, and use pull to open the top this data for a variety of functions throughout your home.
