Technical Specifications
Power supply
10 ... 30VDC or
2x 1.5V AA batteries
typ. 0.07W, max. 1.1W (when
Power consumption
rain sensor heating is on)
Power loss
max. 1.1W
Interfaces
Loxone Air:
868MHz (SRD Band Europe),
4 channels available
915MHz (ISM Band Region 2),
10 channels available
max. Power 3.16mW
Battery lifetime
up to 2 years
Ambient temperature
-30 ... 70°C / -22 ... 158°F
Wind detection range
9 ... 145km/h / 5.6 ... 90mph
Brightness detection range
0 ... 188000lx
Temperature detection range
-40 ... 125°C / -40 ... 257°F
Rain sensor
integrated, heating only when
extern powered
IP44
Safety rating
This device is free of main-
Maintenance & Cleaning
tenance and may only be
cleaned with a dry cloth.
Connection
Wire cross-section
0.08 ... 0.32mm² / AWG28 ... 22
Stripping length
3.5mm / 0.14"
Temperature resistance
-40 ... 125°C / -40 ... 257°F
Information
Contains FCC ID: COR-ZWIR4512AC1
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received,
including interference that may cause undesired operation
Need Help?
loxone.com/support
Loxone Electronics GmbH
Smart Home 1
4154 Kollerschlag
Austria
loxone.com
Weather
Station
Air
Part No: 100245
