"Serenity 100" Fireplace (FPL-100) Assembly Instructions
How-To Assemble Your
SERENITY 100
Outdoor Fireplace
FPL-100
PART NO.
INTERMEDIATE
DIFFICULTY
4'W x 3'4"D x 7'H
APPROX. DIM.
5,620 lbs.
APPROX. WEIGHT
GENERAL SHALE OUTDOOR LIVING PRODUCT WARRANTY
All General Shale Outdoor Living products are warranted to be made from high quality materials that meet or exceed ASTM material standards.
Outdoor Living products are intended for recreational or residential use and are not warranted for any other purpose. The life of the product
depends on correctness of installation and extent of usage. All metal components are subject to normal rust and corrosion.
ANY IMPLIED WARRANTIES ARE HEREBY DISCLAIMED AND ARE EXPRESSLY EXCLUDED.
P.O. Box 3547 / Johnson City, TN 37602 / 1-800-414-4661 / www.GeneralShale.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Serenity 100 and is the answer not in the manual?

Questions and answers

Related Manuals for General Shale Serenity 100

Summary of Contents for General Shale Serenity 100

  • Page 1 GENERAL SHALE OUTDOOR LIVING PRODUCT WARRANTY All General Shale Outdoor Living products are warranted to be made from high quality materials that meet or exceed ASTM material standards. Outdoor Living products are intended for recreational or residential use and are not warranted for any other purpose. The life of the product depends on correctness of installation and extent of usage.
  • Page 2 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Materials included with your outdoor kit. (108) Block “A” (4" x 8" x 16" ; includes 2 extra) (18) Non-Weathered Block “I” (4" x 8" x 16") (16) Block “B” (4" x 8" x 12") Block “D”...

  • Page 3: Firebox Dimensions

    “Serenity 100” Fireplace (FPL-100) Assembly Instructions Course Numbers (Referred to in following instructions) *Fireplace shown with optional thin brick installed. Firebox Dimensions These dimensions are provided for customer information. Firebox Opening (Front): 23 3/8"W x 22"H (±1/4") Inside* (Side to Side): 31 1/4"W x 30 7/8"H (±1/4") Inside* (Front to Back): 23 3/4"D x 30 7/8"H (±1/4")
  • Page 4 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Create a level base using Crusher Run Stone to accommodate the overall footprint of the fireplace. Prepare an area 4'4" wide x 3'8" deep. Remove sod and vegetation. Excavate/remove soft soil as required to provide level stone surface at a minimum of 4"...
  • Page 5 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Build the fireplace (courses 1 through 4). Assemble the fireplace on a level setting base. Dry stack courses 1 through 4 and check fit for fire brick before applying thin set. Adjust gap / position of "A" and "I" blocks to accommodate fire Use supplied thin set between all courses and all blocks.
  • Page 6 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Build the fireplace (courses 5 through 12). Use supplied thin set between all courses and all blocks. Apply thin set to head joints (vertical joints) on courses 5 through 11 (fire box area).
  • Page 7 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Build the fireplace (course 13). Use supplied thin set between all courses and all blocks. Dry stack bullnose units and check fit before applying thin set. 8" 4" x 8" x 34 3/4" Block Lintel NOTE: These lintels are laid flat side down.
  • Page 8 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Build the fireplace (courses 14 through 16). Use supplied thin set between all courses and all blocks. Dry stack course 14 to ensure fit and position before applying thin set. 8" 8" Course 14...
  • Page 9 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Build the fireplace (courses 17 through 19). Use supplied thin set between all courses and all blocks. 4" Typical 4" Typical Course 17 Course 18 NOTE: Lay block with 8" dimensions as height.
  • Page 10 “Serenity 100” Fireplace (FPL-100) Assembly Instructions Step Cover Firebox Opening Lintel (Optional for customers choosing thin brick option). Use supplied thin set mortar to apply thin brick over exposed block lintel. Start at centerline of opening and set brick to the left and right. Thin brick can also be installed with a mortar joint.
