General Shale GATHERING FPS-100 Assembly Instructions Manual

Square fire pit
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

"Gathering" Fire Pit (FPS-100) Assembly Instructions
How-To Assemble Your
GATHERING
Square Fire Pit
FPS-100
PART NO.
BEGINNER
DIFFICULTY
3'4"W x 3'4 x 2'6"H
APPROX. DIM.
1,650 lbs.
APPROX. WEIGHT
GENERAL SHALE OUTDOOR LIVING PRODUCT WARRANTY
All General Shale Outdoor Living products are warranted to be made from high quality materials that meet or exceed ASTM material standards.
Outdoor Living products are intended for recreational or residential use and are not warranted for any other purpose. The life of the product
depends on correctness of installation and extent of usage. All metal components are subject to normal rust and corrosion.
ANY IMPLIED WARRANTIES ARE HEREBY DISCLAIMED AND ARE EXPRESSLY EXCLUDED.
P.O. Box 3547 / Johnson City, TN 37602 / 1-800-414-4661 / www.GeneralShale.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GATHERING FPS-100 and is the answer not in the manual?

Questions and answers

Related Manuals for General Shale GATHERING FPS-100

Summary of Contents for General Shale GATHERING FPS-100

  • Page 1 GENERAL SHALE OUTDOOR LIVING PRODUCT WARRANTY All General Shale Outdoor Living products are warranted to be made from high quality materials that meet or exceed ASTM material standards. Outdoor Living products are intended for recreational or residential use and are not warranted for any other purpose. The life of the product depends on correctness of installation and extent of usage.
  • Page 2 “Gathering” Fire Pit (FPS-100) Assembly Instructions Materials included with your outdoor kit. (32) Block “A” (4" x 8" x 16") (12) Bullnose Block “B” (4" x 8" x 8") Bullnose Block “C” (4" x 4" x 8") Bullnose Corner Block “D” (4" x 8" x 8") (1) Square Fire Pit Insert (1) Thin Set Mix Bag (not pictured below)
  • Page 3 “Gathering” Fire Pit (FPS-100) Assembly Instructions Step Create a level base using Crusher Run Stone to accommodate the overall footprint of the fire pit. Prepare an area 4'wide x 4'deep. Remove sod and vegetation. Excavate/remove soft soil as required to provide level stone surface at a minimum of 4"...
  • Page 4 “Gathering” Fire Pit (FPS-100) Assembly Instructions Step Lay first course of block. Each course will use (8) "A" blocks (4" x 8" x 16"). After laying the first course, check to make sure it is level before proceeding. Step Apply a mixed thin set between each course. Apply away from outside edge to prevent thin set from squeezing out between courses.
  • Page 5 “Gathering” Fire Pit (FPS-100) Assembly Instructions Step Alternate courses (1,2,3,4) to ensure proper bonding . Check to make sure each course is level. Pattern for Courses 1 & 3. Pattern for Courses 2 & 4. P.O. Box 3547 / Johnson City, TN 37602 / 1-800-414-4661 / www.GeneralShale.com...
  • Page 6 “Gathering” Fire Pit (FPS-100) Assembly Instructions Step Lay the top course. Top course consists of 12 "B" blocks, 4 "C" blocks and 4 "D" blocks. Place the rounded edge on the outside; this course will have a 2" overhang on all sides. Place Rounded Edges to the Outside Step...
