Installation

Connecting to Video Equipment

Video Source (example)
Video Cassette Recorder
Audio Output
Cables used for connection
• Video Cable (RCA x 1) ✽
• S-VIDEO Cable ✽
• Audio Cables (Mini Plug) ✽
• Scart-VGA Cable ✽
• Component-VGA Cable ✽
✽ Not supplied.
16
Video Disc Player
RGB Scart
Component Video Output
21-pin Output
(Y, Pb/Cb, Pr/Cr)
Audio Cable Scart
✽
(stereo) ✽
Cable
Component video output
equipment.
high-definition TV source.)
Composite
S-VIDEO
Output
Video Output
Video
S-VIDEO
Cable ✽
Video Cable
Cable ✽
(RCA x 3) ✽
(RCA x 1)
RESET
VIDEO
S-VIDEO
COMPUTER IN /
COMPONENT IN /
AUDIO IN
COMPUTER /
AV
COMPONENT
Terminals of the Projector
Note :
The S-VIDEO jack has priority over the VIDEO jack under the
condition of connecting both the S-VIDEO jack and the VIDEO
jack when selecting AUTO in the Input Menu.
(such as DVD player or
Audio Output
Audio Cable
(stereo) ✽
SERVICE PORT
USB
Note:
When connecting the cable, the power
cords of both the projector and the
external equipment should
disconnected from AC outlet.
be
