- Page 1 Commercial / Industrial Door Operator Installation Instructions NB-2000-HD2 99 W. Hillside Ave. Thomaston, CT 06786 P : 860-283-6211 F : 860-283-6123 www.bfimfg.com info@bfimfg.com...
- Page 2 WARNING! IMPORTANT INSTALLATION INSTRUCTIONS IMPROPER INSTALLATION CAN LEAD TO SEVERE INJURY OR DEATH READ AND FOLLOW ALL INSTRUCTIONS Install only on a properly operating and balanced swing door within the rated values for door weight, door width and operating • torque as stated on the ratings label.
- Page 3 WARNING! IMPORTANT SAFETY INSTRUCTIONS IMPROPER USAGE CAN LEAD TO SEVERE INJURY OR DEATH READ AND FOLLOW ALL INSTRUCTIONS Commercial/Industrial swinging door operator for trained traffic* use only. The manufacturer of this product does not include • external safety devices as a standard feature. Since Entrapment shall be compliant with UL 325 Section 29.4, the addition of external safety devices on swinging door operators is considered redundant.
- Page 4 This force must be £ 50 lb (per UL 325 section 29.3) and be applied near the lock edge of the door. 6. All PLC and Motor Control settings have been preset by brookfield industries, inc.; however, we recommend these values be double-checked with the Parameter sheet supplied.
- Page 5 Door Position Setup and DAU Instructions GT-01/02 Touch Screen 1.Plug the eight prong Phoenix Connector into GT-01/02. For operator series before ʻG,ʼ use the black cable, plug the opposite ROUND end into the PLC unit on the operator. For ʻGʼ series and above, use the gray cable and plug the opposite ROUND end into the receptacle on the end cover of the operator (right side).
- Page 6 5. Youʼll be given a display of the first three user presets (Fig. 7). To edit a preset, simply touch the preset number. 6. A keypad will then display for entering the new preset (Fig. 8). Enter the desired value and touch the ENTER (bent arrow) key to set the value. Press ESC to cancel and go back to the preset list.
- Page 7 DAU Instructions - For Swinging Doors DAU GT-01/02 Touch Screen 1. Plug the eight prong Phoenix Connector into DAU. For operator series before ‘G,’ use the black cable, plug the opposite round end into the PLC unit on the operator. For ‘G’ series and above, use the gray cable and plug the opposite round end into the receptacle on the end cover of the operator (right side).
- Page 8 Door Position Setup Instructions 1. The factory settings are a starting point and may need to be adjusted for each application depending on installation and environment variables. 2. Initiate a signal to have the operator close the door (Close button or Push Open/Close). When operator goes into Latch Check, it will move slowly until it rests fully against the frame.
- Page 9 NB-2000-HD2 Table 1 Minimum Closing Time (seconds) to Latch Check* Door Weight (lbs.) Door Width(in.) 20000 25000 30000 35000 40000 45000 50000 55000 60000 *PER ANSI 156.10. For weights and widths not listed, TIME=(DOOR WIDTH) X (DOOR WEIGHT)^1/2 / 188 Minimum Opening Time (seconds) to Backcheck** **shall be set to the same criteria as closing times.
- Page 10 Rev. Revision note Date Sign Check FRONT ELEVATION (BASE PLATE OUTLINE) (COVER PLATE OUTLINE) WIRE WAY CLASS (2) 24VDC ONLY INPUT Notes: 0.6A REGENERATIVE (4-QUADRANT) 90 VDC MOTOR CONTROL MULTI-SPEED BOARD SPEED BOARD LEGEND PRESET 1 LATCH CHECK (REV) SPEED PRESET 2 BACK CHECK (FWD) SPEED PRESET 3...
- Page 11 Rev. Revision note Date Sign Check Notes: Tolerances Decimal Fractional Angular Drawn by Checked by Date Scale Material...
- Page 12 Rev. Revision note Date Sign Check FRONT ELEVATION (BASE PLATE OUTLINE) (COVER PLATE OUTLINE) Notes: SPEED BOARD LEGEND SIDE ELEVATION Tolerances Decimal Fractional Angular Drawn by BRACKET DETAIL Checked by Date Scale Material...
- Page 13 99 West Hillside Ave. : Thomaston, CT 06787 P: (860) 283-6211 F: (860) 283-6123...
- Page 15 Swinging Door Operator Note: 19 Review Page 2 for notes. Information contained herein is exclusive property of brookfield industries, inc. Review Page 3 for Battery backup wiring detail. V4.3, P-1 and may not be duplicated in part or in whole without written consent...
- Page 16 Notes: 1. Use 4 Amp/110/220 VAC Circuit Breaker on NB-500; Use 8 Amp/110/220 VAC Circuit Breaker on NB-1000 & NB-2000 2. Use 1 Amp/110/220 VAC Circuit Breaker 3. Class (2) 24 VDC Terminals: Power Supply: (1 & 3) Inputs: 9-14 & 19-22 4.
- Page 17 Note 14 N.C. Limit Switch Relay: 110/220 VAC Input IPDT 6A Output Note 14 To line input terminals on page 1 Field Wiring Note: 19 Battery Backup Test 12V 7Ah NP7-12 Battery 12 V Battery Tender Note: 16 Ribbed Battery Backup* Wiring Detail Provides automatic opening during power loss NEMA Enclosure *The battery backup system is an optional addition...
