2100 PSI
Electric Pressure Washer
95032-LM
95032_IM_MAXX2100_REV01_ENG-FR-SP.indd 1
ASSEMBLY, CARE AND
USE INSTRUCTIONS
Model MAXX 2100
READ CAREFULLY
IMPORTANT:
RETAIN THESE INSTRUCTIONS
AND ATTACH RECEIPT TO MANUAL FOR FUTURE
REFERENCE.
WARNING:
This product can expose you to
chemicals including lead, DEHP, DINP, which is
known to the State of California to cause cancer
and or lead to birth defects. For more information
go to www.P65Warnings.ca.gov
Questions, problems, missing parts?
Before returning to your retailer, call (1-866-235-5112)
or email (info@arnorthamerica.com) our customer
service department. They are available from 8:00 a.m. -
5:00 p.m., CST, Monday - Friday. www.arblueclean.com
2019/1/7 下午2:58
Advertisement
Table of Contents
Related Manuals for AR Blue Clean MAXX 2100
Summary of Contents for AR Blue Clean MAXX 2100
- Page 1 2100 PSI Electric Pressure Washer ASSEMBLY, CARE AND USE INSTRUCTIONS Model MAXX 2100 READ CAREFULLY IMPORTANT: RETAIN THESE INSTRUCTIONS AND ATTACH RECEIPT TO MANUAL FOR FUTURE REFERENCE. WARNING: This product can expose you to chemicals including lead, DEHP, DINP, which is known to the State of California to cause cancer and or lead to birth defects.
-
Page 2: Table Of Contents
Troubleshooting ....................... 16 Limited Warranty ......................17 Replacement Parts List ....................18 PRODUCT SPECIFICATIONS PRODUCT SPECIFICATIONS SPECIFICATIONS Max PSI Max GPM Frequency Weight (lbs.) Model (lbs/sq. in.) (Gal/per min) Cold Water Volts (Hz) Amps MAXX 2100 2100 39.6 95032_IM_MAXX2100_REV01_ENG-FR-SP.indd 2 2019/1/7 下午2:58... -
Page 3: Package Contents
PACKAGE CONTENTS PACKAGE CONTENTS PACKAGE CONTENTS 1 .2 G PM M AX PW909383SS Soap – Black M AX 0° – Red 15° – Yellow 25° – Green PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY Hose Holder Spray Gun Handle Spray Gun Trigger Lock Rotary Nozzle Spray Gun Holster O-Ring Replacement Kit... -
Page 4: Safety Information
SAFETY INFORMATION SAFETY INFORMATION SAFETY INFORMATION Please read and understand this entire manual before 9. DO NOT use your power washer when you are under attempting to assemble and operate the product. carefully and only when you are alert. This manual contains information that relates to 10. - Page 5 SAFETY INFORMATION SAFETY INFORMATION SAFETY INFORMATION 25. Protect eyes, lungs, and skin from exposure to 30. NEVER use a water supply to your power washer detergent. that exceeds 150 PSI maximum. 26. Warning-If connection is made to a potable water 31.
-
Page 6: Assembly Instructions
PREPARATION PREPARATION PREPARATION Before beginning assembly of product, make sure all Tools Required for Assembly (not included): Phillips parts are present. Compare parts with package contents screwdriver. list and hardware contents list. If any part is missing or damaged, DO NOT attempt to assemble the product. Please call customer service at 1-866-235-5112. - Page 7 ASSEMBLY INSTRUCTIONS Install nozzle holder (H) to lower frame (G). Secure with two screws (BB). Hardware Used: Screws Axle Pins Screws Cotter Pins Qty. 2 Qty. 2 Cant. 2 Press buttons on lower frame (G) extensions and install handle (B). Lower frame extensions will click when handle is in proper position.
- Page 8 PREPARATION ASSEMBLY INSTRUCTIONS Place power washer unit (F) into position on the lower frame (G). Pull upward on latches that are located on sides of lip, push down until lower latch clicks into place. Locked Unlocked Pull back on collar at one end of high pressure hose Locking Spray Gun (before Lance installation) To lock trigger of spray gun (K), point gun away from you and turn dial to lock (“3”...
- Page 9 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS Attach nozzle (E) and Rotary nozzle (*C) into end of lance (*I) by pressing selected nozzle into place. It will Note: Always push safety lock button to lock trigger Extension Lance Installation when changing lances and nozzles to ensure that they While spray gun (K) is in the locked position, insert do not accidentally eject with force during removal.
- Page 10 ASSEMBLY INSTRUCTIONS Attach Foam Cannon (O) into end of lance by pressing cannon into place. It will make a “click” Foam Cannon Storage Note: Always lock spray gun when changing the foam Store the foam cannon (O) on the back of the power cannon to ensure it does not eject with force.
-
Page 11: Operating Instructions
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS ASSEMBLY INSTRUCTIONS Attach a garden hose to built in garden hose adapter. The water is now connected to your power washer. Note: Flush out garden hose before connecting to garden hose adapter You have now completed the assembly and are ready to begin using your electric power washer. - Page 12 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS squeezing the trigger again. • Squeezing rapidly will cause the auto start feature to miss an on/off cycle that may prevent it from turning on while squeezing trigger after rapid squeezing. Use slow, deliberate trigger pulls to avoid this. •...
- Page 13 OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS • If you hear the motor run intermittently when the trigger is not being squeezed, that is normal. The pump is priming itself so it is ready to operate when the trigger is squeezed. Turn off the power •...
-
Page 14: Care And Maintenance
CARE AND MAINTENANCE Detergents • Turn off the unit. • Use detergents designed for power washers. • Turn off the water supply to the unit. Hardware stores or home centers also have power • Relieve any pressure trapped in the hose by washer detergents for different cleaning projects. -
Page 15: Pump Saver
4) Squeeze bottle to help it into the pump. while being stored in ALL climates. It also assists with protection from internal corrosion. The AR Blue Clean 5) Turn power off when pump saver exits the machine’s part #is: PW64511(16oz. bottle). Order online at water outlet. -
Page 16: Troubleshooting
TROUBLESHOOTING If you have any questions regarding the product, please call customer service at 1-866-235-5112 PROBLEM CORRECTIVE ACTION 1. Make sure the power washer is OFF. Plug in the electrical cord to a grounded 120 volt Unit will not turn on. outlet (no electrical extension cord should be used). -
Page 17: Limited Warranty
TROUBLESHOOTING LIMITED WARRANTY The Warranty of this product is coverd by A.R.North America. This product has a 2 (two) year warranty. Please read the following carefully to understand what each warranty entails: This product is under warranty to the original retail consumer against defects in material and workmanship for a period of 1(one) year and is a complete “bumper to bumper”... -
Page 18: Replacement Parts List
LIMITED WARRANTY REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-866-235-5112, 8 a.m. - 5:00 p.m., CST, Monday - Friday or order online at www.arblueclean.com PW909383SS Soap – Black 0° – Red 15° – Yellow 25° – Green PART DESCRIPTION PART #...
