Image Engineering iQ-LED V2 Setup Instructions page 10

Response time (switch illuminant)
Output data
Maximum / Minimum illumination values
Dimmable
Warm up time
Operating ambient temperature range
Computer requirements
Power supply
Dimension
Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here.
Error! Use the Home tab to apply Überschrift 1 to the text that you want to appear here.
< 50 ms
Real-time measurement of the spectral trend, CCT, CRI, illumination, and
radiant power, during closed-loop link with micro-spectrometer
Depending on application/installation and illuminant (iQ-LED bundle comes as
components WITHOUT any diffusor or sphere to mix the separated LED light
channels) – For intensity examples, please see other Image Engineering iQ-
LED products
Software-based dim function by presetting intensity (lux/watt) while the
closed-loop link with micro-spectrometer or stored different intensity
illuminants on device
< 2 min. at an optimal ambient temperature
Optimal: 22° to 26° degrees Celsius / Maximum: 18° to 28° degrees Celsius
PC with Windows 7 operating system (or higher) / USB port
12 V / 100 W
100 mm x 105 mm x 76 mm iQ-LED PCB incl. CAN-USB connector board
