- Page 1 Bundle V2 Setup instructions September 27, 2018 Image Engineering GmbH & Co. KG · Im Gleisdreieck 5 · 50169 Kerpen · Germany T +49 2273 99 99 1-0 · F +49 2273 99 99 1-10 · www.image-engineering.com...
-
Page 2: Table Of Contents
3.1 Maintenance ......................8 3.2 Care instructions ....................... 8 3.3 Disposal Instructions ....................8 TECHNICAL DATA SHEET .................... 9 Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here. Seite 2 von 11... -
Page 3: Introduction
Do not look directly into the light source when using high intensities or sequences with low response time. • Do not open the device without any instructions from the Image Engineering support team or when connected to the power supply. 2 GETTING STARTED 2.1 Scope of Delivery... -
Page 4: Overview Iq-Led (V2) Board
Error! Use the Home tab to apply Überschrift 1 to the text that you want to appear here. 2.3 Overview iQ-LED (V2) board iQ-LED V2 from the backside 1 power connector 2 CAN-USB adapter connectors 3 iQ-LED ID dip switch... -
Page 5: Connection Of Can-Usb Board / Control Panel Pcb
To create and store illuminants (or sequences) on your device, please follow the instructions in the SW manual. Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here. -
Page 6: Using Several Iq-Led Elements/Dip Switch Id's
PC, the driver will be installed; this could take a few seconds. Hardware Manager: active iQ–LED devices and spectrometer Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here. Seite 6 von 11... -
Page 7: Arrangement Of Iq-Led And Spectrometer
LED’s when using the test mode is set to a much less intense level, but it is still advised to not look directly into the LED’s. Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here. -
Page 8: Additional Information
Observe your national regulations and make sure that third parties can not use the iQ- LED after disposal. Contact Image Engineering if assistance for disposal is required. Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here. -
Page 9: Technical Data Sheet
Illumination stability for most applications +/- 1% when stabilized (2% after switching D illuminants while the first 5 seconds) Image Engineering Error! Use the Home tab to apply Titel to the text that you want to appear here. Seite 9 von 11... - Page 10 Depending on application/installation and illuminant (iQ-LED bundle comes as components WITHOUT any diffusor or sphere to mix the separated LED light Maximum / Minimum illumination values channels) – For intensity examples, please see other Image Engineering iQ- LED products Software-based dim function by presetting intensity (lux/watt) while the...
- Page 11 Weight 0.5 kg (Only iQ-LED v2 device) Starter bundle version: 1 x iQ-LED V2, 1 x CAN-USB connector board, 1 x micro switch controller board, USB cable, power supply, calibrated micro-spectrometer (detailed Delivery includes specs see EX2 VIS datasheet) with 1m metal coated fiber, control software...
