- Page 1 Kitchen hood dAh 251-13 USER’S MANUAL...
-
Page 2: Table Of Contents
251-13 www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 3 Overall dimensions and technical data ........................... 3 Installation ......................................4 Connection to power mains ..............................5 Technical maintenance ................................6 Manufacturer’s warranty ................................7 Certificate of acceptance ................................11 Seller information .................................. -
Page 3: Purpose
251-13 www.blaubergventilatoren.de PURPOSE The kitchen exhaust hood is designed for installation into ventilation systems of small and medium sized spaces. Equipped with lamps and a polyester filter. This User’s manual covers the installation, care and maintenance of the unit. -
Page 4: Installation
251-13 www.blaubergventilatoren.de INSTALLATION The mounting accessories and screws are included in the delivery set. The kitchen exhaust hood is supplied with a cable and a grounded power connector. Flange connector installation Mount the flange with the valve to the exhaust opening of the kitchen hood. -
Page 5: Connection To Power Mains
251-13 www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. -
Page 6: Technical Maintenance
251-13 www.blaubergventilatoren.de TECHNICAL MAINTENANCE Maintenance operations of the unit are required twice per month. They include general cleaning of the unit and the following operations: 1. Filter maintenance. To remove the filter cartridge, press on the front latches. Remove the filter and the fabric insert by releasing the detent. Wash the filter in a warm detergent solution. Alternatively put the filter in a dishwasher. -
Page 7: Manufacturer's Warranty
251-13 www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 8 251-13 www.blaubergventilatoren.de...
- Page 9 251-13 www.blaubergventilatoren.de...
- Page 10 251-13 www.blaubergventilatoren.de...
-
Page 11: Certificate Of Acceptance
This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. Customer’s Signature Seller’s Stamp INSTALLATION CERTIFICATE The DAH 251-13 unit is installed pursuant to the requirements stated in the present user's manual. Company name Address Phone Number Installation Technician’s Full Name... - Page 12 www.blaubergventilatoren.de B169EN-02...
