LVDS (R3399X-2C)
INVERTER (R3399X-2C) LVDS /EDP Inverter
LVDS_BKLT
(R3399X-2C)
LVDS_POWER
(R3399X-2C)

2-1 Rear I/O Connectors

*For Rear IO please refer to Page-3.
Icon P/N
DCIN
HDMI1
HDMI1
USB1
USB20_1 USB 2.0 Port
LAN2
LVDS Header
LVDS Backlight VCC Select Jumper
LVDS LCD Power VCC Select Jumper 6-pin Block
Chapter 2
Hardware Installation
Name
12V DC-in
Power Jack
Top: HDMI-IN
Bottom: HDMI-Out
HDMI-Out Port
USB 3.0 Port
Megabit
RJ-45 LAN Port
Function
For user to connect compatible power adapter to
provide power supply for the system.
Top: To connect display input device that support
HDMI specification.
Bottom: To connect display output device that
support HDMI specification.
To connect display output device that support
HDMI specification.
To connect USB keyboard, mouse or other
devices compatible with USB specification. USB
3.0 ports supports up to 5Gbps data transfer rate.
To connect USB keyboard, mouse or other
devices compatible with USB 2.0 specification.
This connector is standard RJ-45 LAN jack for
Network connection which supports 10/100 Mbps
transfer rate.
7
30-pin Block
6-pin Block
4-pin Block
