ISE MT-ULTRA Assembly/Installation Instructions

Assembly & Installation Instructions:
Swap MT-ULTRA Mouse Platform:

Parts Included

A
MY-ULTRA Mouse Platform
Qty: 1
Required
Swap Keyboard Platform
1

Configuring Swap Mouse Platform for Left or Right Handed Use

Swap MT-ULTRA Mouse Platforms are
ambidexterous and can easily be installed for
right or left handed use.
1.1 Loosen the Clamp Knob to allow Mouse
Platform (A) to be slipped over the
Keyboard Platform on either the right or
left hand side.
1.2 Mount to Keyboard Platform on the front
third of the Keyboard Platform, near the
Wrist Rest.
1.3 Tighten Clamp Knob to lock into place.
1.4 If you've mounted for left hand use, re-
locate the Mouse Trap to the rear of the
Mouse Platform.
2

Place Mouse Pad

Peel the backing off the Mouse Pad (B) and place in either the
right handed or left handed location. The Mouse Pad provides
improved traction and pointing accuracy. It can be repositioned
by simply peeling it up and placing it elsewhere.
1 of 2
B
Mouse Pad
Qty: 1

Tools Required

No tools are required to mount the MT-ULTRA to the
Swap Keyboard Platform
Re-locate
Mouse Trap
1.4
A
Left Handed
Swap Keyboard
Platform sold
separately
Workrite Ergonomics | (800) 959–9675 www.workriteergo.com
1.1 1.3
Loosen Tighten
1.2
1.2
1.1 1.3
Loosen Tighten
Shown with Swap Keyboard Platform
on Leader Arm
Clamp Knob
A
Right Handed
Worksurface
B
A
