Altronix SMP7PM Manual

The SMP7PM is a supervised power supply that converts a low voltage AC input into 12VDC or 24VDC output with 6 amp
continuous supply current.
Input:
• Input 28VAC

(Voltage Output/Transformer Selection Table).

Output:
• 12VDC or 24VDC selectable output.
• 6 amp supply current.
• Output fuse is rated 15A/32V.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Maximum charge current 0.7 amp.
Voltage Output/Transformer Selection Table:
Output VDC Switch Position Max. Load DC
12VDC SW1 Closed
24VDC SW1 Open
The SMP7PM should be installed in accordance with The National Electrical Code and all applicable Local Regulations.
1. Mount the SMP7PM in the desired location/enclosure.
2. Set the SMP7PM to the desired DC output voltage by setting the SW1 switch (Fig. 1a, pg. 2) to the
appropriate position (Voltage Output/Transformer Selection Table).
3. Connect proper transformer to the terminals marked [AC] (Voltage Output/Transformer Selection Table).
Use 18 AWG or larger for all power connections (Battery, DC output).
Keep power-limited wiring separate from non power-limited wiring (115VAC / 60Hz Input, Battery Wires).
Minimum 0.25" spacing must be provided.
CAUTION: Do not touch exposed metal parts. Shut branch circuit power before installing or servicing equipment.
There are no user serviceable parts inside. Refer installation and servicing to qualified service personnel.
4. Measure output voltage before connecting devices. This helps avoiding potential damage.
5. Connect devices to be powered to the terminals marked [- DC +].
6. When the use of stand-by batteries is desired, they must be lead acid or gel type. Connect battery to the terminals
marked [- BAT +] on the board (battery leads included). Use two (2) 12VDC batteries connected in series for
24VDC operation.
Note: When batteries are not used, a loss of AC will result in the loss of output voltage.
7. Connect appropriate trouble reporting devices to AC Fail & Low battery supervisory relay outputs marked
[NC, C, NO]. Use 22 AWG to 18 AWG for AC Fail / Low Battery reporting.
AC Failure will report in 5 minutes. For a 6 hour delay on reporting cut resistor J1.
Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF
SMP7PM
Supervised Power Supply/Charger

Overview:

Specifications:

TransformerRequirements
(Recommended Altronix Part #'s)
6 amp 24VAC or 28VAC / 175VA (T2428175)
6 amp 24VAC or 28VAC / 175VA (T2428175)

Installation Instructions:

LED Diagnostics:

Power Supply Status
Normal operating condition
Loss of AC, Stand-by battery supplying power
No DC output
Loss of AC. Discharged or no stand-by battery. No DC output
Battery Backup (cont'd):
• Zero voltage drop when switching over
to battery backup.
Supervision:
• AC fail supervision (form "C" contacts).
• Battery presence and low battery supervision
(form "C" contacts).
Indicators:
• AC input and DC output LED indicators.
Board Dimensions (W x L x H approximate):
7.045" x 4.266" x 1.25" (108.36mm x 179mm x 31.8mm).
