4-Assembly And Installation Instructions

1. Install the leg levelers to the bottom of the lower cabinet.
2. Place the lower cabinet in the desired location and adjust
each leg leveler until the lower cabinet is level from front to
back and side to side.
3. Install the step/dart skirt assembly flush to the floor using
the four bolts provided.
Figure 2.1: Installation of lower cabinet
7
A bolt set consists of a
M8 bolt, a lock washer
Leg Leveler
and a washer
Figure 2.2: Lower cabinet complete unit
