B Y M E D A L IS T
BASIC SETUP AND
INSTALLATION MANUAL
AIM FOR EXCELLENCE
Please read these instructions carefully before
setup and installation of the machine.
Keep this manual in a safe place for later
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spectrum E-Tec and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Medalist Spectrum E-Tec

Summary of Contents for Medalist Spectrum E-Tec

  • Page 1 B Y M E D A L IS T BASIC SETUP AND INSTALLATION MANUAL AIM FOR EXCELLENCE Please read these instructions carefully before setup and installation of the machine. Keep this manual in a safe place for later reference.
  • Page 2 Table Of Contents Safety Precautions ............1. Basic Specifications ..........2. Spectrum Parts ..........3. Cabinet Configuration ..........4. Assembly And Installation Instructions ...... 5. Camera Installation And Setup ........6. Technical Information ..........
  • Page 3 BY MEDALIST Safety Precautions Spectrum has been engineered and manufactured to ensure personal safety. However, improper use can result in potential electrical shock or fire hazard. You must observe the following basic rules for installation, use and servicing. Failure to do so may defeat the safe guards incorporated into the Spectrum and may result in injury.
  • Page 4 Make/Model MSI K8MM-V AMD, Socket 754, Sempron 2500/2600 Memory 256 MB/DDR Embedded peripherals Audio, Video, USB, LAN 5. *I.O. Board Designed and developed by Medalist I.O. Board Software version 5.4 6. *Power Supply Type Input 120/230 VAC (Selectable) Output +3.3Vdc/28A...
  • Page 5 BY MEDALIST 2 - Spectrum Parts Check List Unpacking and Inspection 1. Remove Spectrum lower cabinet, upper cabinet, and LCD monitor/crown from the boxes and inspect for any damage. 2. Confirm that all parts are included. Parts List Spectrum upper cabinet assembly...
  • Page 7 BY MEDALIST...
  • Page 8 Item Name Function For display. Can adjust the display quality by using the LCD button located on the right LCD Monitor side of the LCD Primarily to register dart scores, also used Target to input various information Red Select/ Interfaces with software. Normally this button Change Button is used to scroll cursor and change players Interfaces with software.
  • Page 9 BY MEDALIST 4 - Assembly And Installation Instructions 1. Install the leg levelers to the bottom of the lower cabinet. 2. Place the lower cabinet in the desired location and adjust each leg leveler until the lower cabinet is level from front to back and side to side.
  • Page 10 Install 1 bolt set from outside Monitor unit Install 2 bolt set from inside Upper Cabinet Fiber Door Locks Figure 3.1: Installation Of Upper Cabinet Figure 3.2: Upper Cabinet Complete Unit Using two people, lift the upper cabinet and place it on top of the lower cabinet.
  • Page 11 BY MEDALIST Connect the connectors from the lower wiring harness to the upper wiring harness. Connect the power cord to power input module on the back of the cabinet. 11. Using the ground cable provided, attach the GND Terminal to earth ground.
  • Page 13 BY MEDALIST 5 - Camera Installation And Setup (Digital Camera Optional) Installation 1. Thread the USB camera cable through the 1” hole in the upper right side of the game. 2. While holding the camera box to the upper right hand side of the game with the camera hole facing outwards, thread two 6mm bolts from the inside of the game into the camera box inserts.
  • Page 15 BY MEDALIST...
  • Page 17 BY MEDALIST...
  • Page 19 BY MEDALIST...
  • Page 21 BY MEDALIST...
  • Page 22 6B. I.O. Board Layout Port Description Input Output Load Program ISP RS232 Communication DC Power Audio Signal Input Audio Signal Output To Speaker Target Input Button/Lights Input Signal Of Coin Count- Player Change Sensor Missed Dart Sensor CN10 Bill Validator Input CN11 Soft Power Down CN12...
  • Page 23 BY MEDALIST...
  • Page 24 6C. Back Panel Of PC Unit Keyboard Mouse L-Out (Optional) L-In Figure 12: Back Panel Of PC Unit Name Function Connect to Supply AC Power To PC AC Power Input AC Power Unit Serial Communication With Com Port DB9 Cable I.O.
  • Page 26 7 - Troubleshooting No Power 1. Check for correct voltage at wall receptacle using digital voltmeter. 2. Check fuse with digital voltmeter or continuity tester. 3. Remove power cord and check wiring from AC power cord to power supply. 4. Reapply power cord and check for correct voltage at power supply AC input plug.
  • Page 27 BY MEDALIST No Lamps (Continued) 4. If voltage is not present, trace the wiring back to the terminal strips located behind the power supply using a digital voltmeter. 5. If voltage is present but lamps do not work, install a new lamp holder.
  • Page 28 General Settings will allow you to change the number of times Correct-A-Dart can be used. General Settings allows you to turn on/off Handicapping, Non Cut-Throat Games, Medalist Rating, Out Chart Displayed and Freeze Warning You can also set the pricing for Doubles and Trios in...
  • Page 29 BY MEDALIST Selecting Game Settings (Continued) 7. Player Pix Options Set Happy Hour and Regular Pricing. Password allows you to give a password to the location in case they would like to delete pix that have been placed on the board...
  • Page 30 Selecting Report (Continued) 3. Delete Credits Clears any credits currently on the board 4. Delete Photos Brings up a screen to show you how to delete any photos currently on the dart board Selecting Diagnostics 1. Matrix A target will appear on screen. To check your Matrix touch segments on the dart board and see if they correspond to the screen 2.
  • Page 31 BY MEDALIST Selecting File Load Setting Selecting File Load Setting allows you to load either Factory Settings 1, 2 or 3. Game Factory Setting 1 Factory Setting 2 Factory Setting 3 1101 1501 Cricket Standard Random Select-A Hidden U Pick-I Pick...
  • Page 32 Erase Credits Menu (Y/N) Menu (Y/N) Menu (Y/N) Menu (Y/N) Menu (Y/N) Playoff Doubles Coin4 Slot# Coin Timer (ON/Off) Load Setting Medalist Rating Credits/Player $ = # Credit Displayed Overkill Displayed Displayed Singles Credit(s) # Singles Credit(s) # Singles Credit(s) #...
  • Page 33 Mida-Medalist Master Parts List ..Genesis ....Avanti ..... ( T ) ....Omni ..
  • Page 34 Upper Cabinet Description Item Code PA 0001 Avanti - for top mount dart board; includes wiring harness, speaker with cover, light assemblies, fan with guards, hand cups, power input module, side mount plugs, main board mounts, latch hooks, LCD power harness PE 0001 0 Elite (T) Model O*...
  • Page 35 Description Item Code PO 0001 Omni - for mid mount dart board; includes wiring harness, speaker with cover, light assemblies, fan with guards, hand cups, power input module, main board mounts, latch hooks, camera plugs, terminal blocks, LCD mounting rack, LCD power harness PI 0001 Ion - to be defined Lower Cabinet...
  • Page 36 Description Item Code PO 0011 Omni - for mid mount dart board; includes leg levelers, ground wire, complete coin door assembly (without coin mechs), meter, back door with lock, mail slot cover, latches, vent grill, wiring harness, decals PI 0011 Ion - to be defined Door Description...
  • Page 37 Cabinet Description Item Code Side Door PT 0002 PG 0101 Leg Leveler - Genesis PA 0101 Leg Leveler - all boards made in Thailand PA 0102 Step - with rubber and trim decal not included PA 0103 Step Rubber PA 0104 Step Trim PA 0105 Bolt...
  • Page 38 Description Item Code PA 0131 Ribbon Cable Clamp - with clip PA 0142 Ribbon Cable Hanger PG 0113 Hinge Assembly Genesis - with bolts and nuts PA 0113 Hinge Assembly - all boards made in Thailand, with cabinet and door mounting hardware PA 0139 Hinge Safety Screw...
  • Page 39 Description Item Code PA 0123 Mount Hole Plug - small PG 0124 L Light Diffuser - Genesis - left PG 0124 R Light Diffuser - Genesis - right PE 0124 L Light Diffuser - all top mount boards made in Thailand, left PE 0124 R Light Diffuser - all top mount boards made...
  • Page 40 Description Item Code PA 0144 LCD Bracket - Genesis - includes mounting hardware PA 0130 Speaker Grill Unit - universal with screws PE 0133 Vent Filter PE 0134 Fan Guard PE 0135 Camera Box - with hardware, decal PE 0136 Camera Box Hardware - bracket with bolts, nuts and washers...
  • Page 41 Decal Description Item Code Step - universal PA 0300 Distance - universal PG 0301 Star - Cabinet - Genesis And Avanti PG 0302 Star - Cabinet - Genesis Kit - upgraded to PE 0303 Elite Spectrum - Cabinet - all boards except PE 0304 Genesis Swoop - Genesis And Avanti...
  • Page 42 Description Item Code PA 0310 Target Ring - Grey - Genesis and Avanti PE 0311 Target Ring - Black - Elite, Omni, Ion, Genesis and Avanti Kits PG 0312 Monitor - Genesis - grey PE 0312 Monitor - Genesis Kit - full color PA 0313 LCD - Avanti...
  • Page 43 Description Item Code PA 0208 Triple - Blue PA 0209 Block Black PA 0210 Block Grey PA 0211 Double Red PA 0212 Double Blue PG 0221 Catch Ring Section - standard thread, US made PG 0222 Catch Ring Screw - standard thread PA 0213 Rubber PA 0214...
  • Page 44 Description Item Code PA 0218 - with washer, spring washer Knurled Nut - Metric PA 0219 - with washer, spring washer Wing Nut - Metric PA 0223 Mounting Bolt - Backboard - with lock nut, wing nut, washer, spring washer PA 0231 Mounting Bolt - Target - with knurled nut,...
  • Page 45 Description Item Code PA 0455 Coin Mech - Korea 500, Imonex PA 0458 O Coin Mech New Zealand 1.00, Imonex PA 0458 T Coin Mech New Zealand 2.00, Imonex PA 0459 Coin Mech Canada, Imonex PA 0460 O Coin Mech Australia 1.00, Imonex PA 0460 T Coin Mech...
  • Page 46 Description Item Code PA 0418 Vault Assembly PA 0419 Coin Separator PA 0413 S Coin Switch - with side actuator wire PA 0420 Meter PA 0421 Interlock Switch Video Description Item Code PA 0508 LCD 17” - Sinai - with video cable and power harness for ATX power supply, black plastic case, tempered glass, C grade PE 0508...
  • Page 47 Description Item Code PE 0503 LCD Inverter Board -model must be defined PA 0516 LCD Power Adaptor - with cord, for Genesis conversions Electrical Description Item Code PG 0601 Main Board - Genesis, Avanti, Omni - with EPROMS, refurbished, availability unknown PG 0602 EPROM, 8 Meg - Genesis - programmed...
  • Page 48 Description Item Code PE 0630 Fan - HD PE 0612 Fan - Cabinet - universal, with guards PE 0631 Fan - CPU - with heat sink PA 0613 Target Interface Board PE 0614 Power Supply - ATX, 350W PG 0615 Power Supply - Switching PA 0618 Fluorescent Lamp Assembly - Elite...
  • Page 49 Description Item Code PA 0676 Y Power Cord - Elite Japan - Type A 10A PA 0676 B Power Cord Thailand - Type A 10A PA 0676 R Power Cord India - Type D 10A PA 0676 W Power Cord Korea - Type C 10A PA 0676 P Power Cord United Kingdom...
  • Page 50 Medalist Marketing Corporation 201C Frontage Rd. N. Pacific, WA 98047 USA Tel: 1-253-939-2900 Fax: 1-253-939-0128 Mida-Medalist Entertainment Public Co., Ltd. 96/2 Moo 4, Tambol Lamphaya, Amphur Muang Nakornpathom, Thailand 73000 Tel: 66 (0) 3427-2581-3 Fax: 66 (0) 3427-2585 Medalist USA Asia 2F Nihon Build Mihashi 1 Chome Bldg.
