Harbor Freight Tools Pittsburgh 95122 Assembly And Operation Instructions Manual

12 ton hydraulic gear puller kit
Hide thumbs
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual
Brought to You by www.snapwhole.com
12 Ton Hydraulic
Gear Puller KiT
asseMbly and oPeraTion insTrucTions
Due to continuing improvements, actual product may differ slightly from the product described herein.
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
To PreVenT serious injury, read and undersTand
all warninGs and insTrucTions before use.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
for technical questions or replacement parts, please call 1-800-444-3353.
Model
95122
. All rights reserved. No portion of this
®
®

Advertisement

loading

Related Manuals for Harbor Freight Tools Pittsburgh 95122

Summary of Contents for Harbor Freight Tools Pittsburgh 95122

  • Page 1 . All rights reserved. No portion of this © ® manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. for technical questions or replacement parts, please call 1-800-444-3353.

  • Page 2: Specifications

    Brought to You by www.snapwhole.com specifications 3 jaw puller with hydraulic Pressure Capacity 24,000 lb. (12 tons) Type cylinder 4 settings for 4”, 6”, 8” and Size Capacity Jaw Reach 3” Min. - 6” Max. 10” Bearings Cylinder Jaw Spread 4”...
  • Page 3 Brought to You by www.snapwhole.com use eye and ear protection. Always wear ANSI approved impact safety glasses and full face shield. do not overreach. Keep proper footing and balance at all times. Do not reach over or across running machines. Maintain tools with care.
  • Page 4 (6) Connector Plates (3) Bearing Centers If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual. assembly Thread the Puller Sleeve onto the Puller Unit about half way up.

  • Page 5: Operation

    Brought to You by www.snapwhole.com operation This tool is designed to pull bearings, pulleys and the like from shafts. The jaws are designed to grip the bearing from the outside or inside, whichever offers the better grip. The piston will push on the central shaft while the jaws pull away.

  • Page 6: Parts List

    Brought to You by www.snapwhole.com Maintenance Lubricate all threads periodically to keep them operating smoothly. Keep the Piston Rod (8) in the filly retracted position while in storage, to prevent rust or damage. If rust appears on any part of the tool, remove it with a penetrating oil. Lightly oil while in storage.

  • Page 7: Limited Lifetime Warranty

    Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the life of the product. This warranty does not apply to damage due directly or indirectly to misuse, abuse, negligence or accidents;...
