PARASOL Z VAV c
Installation - Commissioning - Maintenance
Content
Symbol explanation ..................................................... 1
Dimensions and weights .................................... 2
Dimensions ................................................................. 2
Weight ....................................................................... 2
Installation .......................................................... 3
Suspension bracket ..................................................... 3
Accessory - Quick bracket ........................................... 4
Accessory - Mounting in concealed T-bars ................... 5
Accessory - Fold-out coil ............................................. 6
Water connection ....................................................... 7
Wiring diagram ........................................................... 8
Air connection ...........................................................11
Commissioning .................................................. 12
K-factor setting ......................................................... 12
ADC ......................................................................... 13
Maintenance ...................................................... 14
Symbol explanation
Symbols on the machine
This product complies with applicable EU directives
Symbols in this user manual
Warning/Caution!
19/10/2020
Art. 942428062
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Swegon Parasol Zenith VAV 600
Summary of Contents for Swegon Parasol Zenith VAV 600
-
Page 1: Table Of Contents
PARASOL Z VAV c Installation – Commissioning – Maintenance 19/10/2020 Art. 942428062 Content Symbol explanation Symbols on the machine Symbol explanation ............. 1 Dimensions and weights ........2 This product complies with applicable EU directives Dimensions ..............2 Weight ............... 2 Installation ............ -
Page 2: Dimensions And Weights
1873 936.5 333.5 1942 * Dimensions refer to products with air connection ø125/ø160. ** With a sensor module in the face plate the height measurement G and H increases by 12 mm. Swegon reserves the right to alter specifications. 19/10/2020... -
Page 3: Installation
- c (mm) c - c (mm) X (A1) X (A2) 398 +10 262 +10 1200 998 +10 862 +10 1800 1598 +10 1462 +10 SYST MS 2 0 m m 19/10/2020 Swegon reserves the right to alter specifications... -
Page 4: Accessory - Quick Bracket
- c measurement Air connection side Short side Long side Length of the unit c - c (mm) c - c (mm) < 320 1200 < 1020 900-1020 1800 < 1530 900-1530 Swegon reserves the right to alter specifications. 19/10/2020... -
Page 5: Accessory - Mounting In Concealed T-Bars
PARASOL Zenith VAVc Accessory - Mounting in concealed T-bars To centre the product when mounting in concealed T-bars. 90° Recommended number of plates per product. Length of the unit 1200 1800 19/10/2020 Swegon reserves the right to alter specifications... -
Page 6: Accessory - Fold-Out Coil
Accessory - Fold-out coil PARASOL Zenith VAV with fold-out coil (accessory) for easy access and cleaning when stringent demands are made on hygiene. The accessory, fold-out coil, requires flexible connecting hoses on the water side. Swegon reserves the right to alter specifications. 19/10/2020... -
Page 7: Water Connection
PARASOL Zenith VAVc Water connection PARASOL Zenith VAV 600 / 1200 / 1800 Important! Värme retur/ Kyla retur/ Heating return Cooling return Värme tillopp/ Kyla tillopp/ Heating supply Cooling supply 942256009 NOTE! Use support sleeves inside the pipes together with compression ring couplings. -
Page 8: Wiring Diagram
3xRJ12 Cable USB-RJ12 Motor Cable adapter 24 V AC / DC Adapter VOC Sensor Pressure sensor 3xRJ12 (Modbus) A. Connection when a VOC sensor is used Sensor module Inputs Outputs Motor ModBus Swegon reserves the right to alter specifications. 19/10/2020... - Page 9 Modular 6/6 RJ12 Modular 6/6 RJ12 | 22 | 23 | 24 | 25 | | 22 | 23 | 24 | 25 | MB id 4 MB id 1 Master Slave id 1 19/10/2020 Swegon reserves the right to alter specifications...
- Page 10 PC with the help of Cable converter Switch for termination resistance. USB-RJ12 On the last sensor module in the circuit switch 1 is set to On. Swegon reserves the right to alter specifications. 19/10/2020...
-
Page 11: Air Connection
1. Unscrew the screws from the sleeve and cover 2. Change the location of the sleeve and cover 3 - 4. Screw the sleeve and cover in position with screws on the new side 19/10/2020 Swegon reserves the right to alter specifications... -
Page 12: Commissioning
In the example from the table for a PARASOL Zenith VAV with length 1200, ø125, k-factor 2.5, turn the knob to 44°. Tighten the screw again when the marking is set on the required number of degrees. K-factor table Knob Swegon reserves the right to alter specifications. 19/10/2020... -
Page 13: Adc
PARASOL Zenith VAVc Fan-shape X-shape - 4 0 ° 0° + 4 0 ° 0 ° + 4 0 ° 0° Examples of ADC settings -40° 40° 19/10/2020 Swegon reserves the right to alter specifications... -
Page 14: Maintenance
PARASOL Zenith VAVc Maintenance Swegon reserves the right to alter specifications. 19/10/2020... - Page 15 PARASOL Zenith VAVc 19/10/2020 Swegon reserves the right to alter specifications...
- Page 16 PARASOL Zenith VAVc Swegon reserves the right to alter specifications. 19/10/2020...
