4.2

Indicator functions

ZERO
Displayfunctions ( only the black signs are active, not the grey signs)
When the load has been lifted too high, arrow down is ON.
When the reference height has been reached, the reference level stripe will be
encircled.
The refence height is almost reached, lift very slowly, 1 arrow is ON.
Lift slowly, 2 arrows are ON.
Lift fast, 3 arrows are ON.
-
The weight shown is negative.
M
The weight has been stored in the memory.
LB
Display shows weight in pounds (to be set by parameter settings menu).
KG
Display shows weight in kilogram (standard setting)
Low bat indicator
TOTAL
ON
OFF
