Diodes; Ferrite; Eurorack Power Socket; Vactrols - JOLIN LAB TABOR Build Manual

diodes:

They are placed in vertical position.
Mind their polarity, the horizontal line (white) on the PCB needs to match the horizontal line (white)
on the component.
2 D2, D6

ferrite:

Snap them in. Don't mind their polarity.
2 FB1, FB2

eurorack power socket:

Place the socket matching the drawing on the PCB.
tip: solder one pin and check. If the socked is aligned solder all the other pins.
1 J1 EURORACK_HEADER

vactrols:

Match the short leg of the vactrol with the squared solder pad on the PCB.
tip: it's easier to bend at 90° degree all the four legs before trying to fit the vactrol in place.
9 U1, U4, U5, U6, U8, U9, U10, U12, U13

electrolytic capacitors:

Mind the cap: short leg (-) goes in the hole in the white side of the drawing on the PCB.
1 C22
1 C15
1 C16
1 C17
2 C1, C7
2 C14, C20
1 C18
3 C2, C8, C11

film capacitors:

Snap them in. Don't mind their polarity.
2 C13, C21
1 C23
check if everything is in place and then you are done with the brain board
if you need a break there are a lot of good ol' cat videos on the internet
1N5817
FERRITE
47u
470u
330u
680u
22u
1u_audio
1u
10u
100n_audio
750n
VTL5C1
4
