D Convenient functions for transmit

• Break-in function (p. 6-3)
➥ Push [VOX/BK-IN] several times to select the
break-in OFF, semi break-in and full break-in.
• "BK IN" or "F-BK IN" appears when the semi break-in
or full break-in function is set to ON, respectively.

D About CW reverse mode

Push
BFO
Interference Desired signal
CW mode (LSB side)

D About CW pitch control

D CW side tone function

[MONI GAIN]
BFO
Interference Desired signal
CW-R mode (USB side)
[CW PITCH]
RECEIVE AND TRANSMIT
CW-R (CW Reverse) mode receives CW signals with a
reverse side CW carrier point like that of LSB and USB
modes.
Use when interfering signals are near a desired signal
and you want to change the interference tone.
➥ During CW mode, push [CW] to select CW and CW-
R mode.
The received CW audio pitch and monitored CW audio
can be adjusted to suit your preference (300 to 900 Hz
in 25 Hz steps) without changing the operating fre-
quency.
➥ Rotate [CW PITCH] to suit your preference.
• Adjustable within 300 to 900 Hz in 25 Hz steps.
When the transceiver is in the receive condition (and
the break-in function is OFF— p. 6-3) you can listen to
the tone of your CW signal without actually transmit-
ting.
This allows you to match your transmit signal exactly to
another station's. This also convenient for CW prac-
tice. CW side tone level can be adjusted with [MONI
GAIN].
4-5
4
