Wired Lan Setup - United Technologies Interlogix UltraSync Training Manual

UltraSync SMART HOME MANAGEMENT HUB
™

Wired LAN Setup

Wired LAN connection is the easiest to set up, but requires a
physical Ethernet connection to the UltraSync panel. You will
need to provide the internet connection and Ethernet router.
Connect UltraSync to power source
o
Connect ethernet cable to the back side of the UltraSync panel
o
On the panel:
o
Press "Menu"
•
Press the "8" button
•
Enter your Installer pin (9713)
•
Press the "6" button
•
Write down the IP address
•
If you hear "IP Address is not configured," wait 30 seconds and try
•
again
Enter the IP address into address bar of a web browser and log in
o
© 2017 United Technologies Corporation. Slide 30
